Episode #461 - May 2nd, 2014

Posted 4 months back at Ruby5

Test-induced design damage, Frocking the console, Advanced Rake and Mutation Testing

Listen to this episode on Ruby5

Sponsored by New Relic

New Relic

Test-induced design damage

we are still feeling the shockwaves from DHH's keynote at RailsConf where he denounced TDD and suggested we focus more on writing clear code
Test-induced design damage

priscilla

priscilla frocks up your console by decorating your text in Colored Strings or unicode emojis
priscilla

Mutation Testing with Mutant

Arne Brasseur posted an article about using Mutant to do mutation testing
Mutation Testing with Mutant

worldcup2014.db

Gerald Bauer has updated and released the sportdb gem with a SQLite Database of the worldcup qualifiers.
worldcup2014.db

Thinking in Types

Posted 4 months back at GIANT ROBOTS SMASHING INTO OTHER GIANT ROBOTS - Home

Here at thoughtbot, there has a been a lot of interest in Functional Programming in general and Haskell in particular. As someone with a bit of Haskell knowledge, I’ve been happy to field a lot of questions and take part in many discussions.

One such question came about when a colleague of mine was stuck attempting to do something in Haskell that seemed conceptually simple but resulted in a type error. After talking through the issue and coming up with a solution, I realized that this little exercise was actually quite interesting.

While a particular form of polymorphism, common in object-oriented languages, translated very well to Haskell, a related technique was not permitted by the language’s type system. In this post, I’d like to outline a simplified version of the task and how this limitation was overcome. Hopefully you’ll see that by working with the type system rather than against it, we find unexpected benefits in the resulting design.

The Task

The system my colleague was building models a Pong-like game. There are two players and a ball, all of which need to be rendered on screen. We’re going to avoid any discussion of the graphics library used to accomplish this and focus only on the task of flexibly sharing this behavior across the two kinds of objects we have in our domain. This simplification should allow the Haskell examples to make sense to someone not familiar with the language.

This task is well-suited to polymorphism with an object-oriented slant. We could define some Renderable interface and have our two object types (presumably Ball and Player) conform to that interface. This way, we can simply tell an object, whatever it is, to render itself.

In Ruby, we can do this easily with duck typing; there is no safety but it is concise and flexible. In Java, we could define an actual Interface and get some form of type checking. Things would be a bit safer but also very verbose.

This approach translates well to Haskell thanks to a feature called type classes. They provide a concise, flexible, and completely type safe way to define interfaces which multiple types can implement. In order to understand the problem I want to discuss, we’ll need to digress just a little and explain what these are and how they work.

Type Classes

A type class defines a set of functions which must be implemented for a type to be considered in that type class. Other functions can then be written which operate not on one specific type, but on any type which is in its given class constraint.

An example should help.

For a type to be Showable or in the Show type class, we have to define how to represent it as a String. Here is how the desired interface is described:

class Show a where
    show :: a -> String

It’s common to represent “any type” with the variable a. The above declaration states that for some type a to be in the Show class, you must define the function show which takes that type as argument and returns a String.

Imagine we declare a type representing people by their age and name:

data Person = Person Int String

A value of type Person can be built by giving an Int (their age) and a String (their name) to the constructor also called Person. It’s common to use the same word for the type and the constructor since there is no ambiguity when either is used. It would’ve also been fine to say:

data Person = BuildPerson Int String

But this is uncommon in cases where there is only one constructor.

Now that we have all of these people in our domain, we can specify how to represent them as Strings by implementing an instance of Show for Person:

instance Show Person where
    show (Person age name) = name ++ ", " ++ show age ++ " years old"

The left hand side uses pattern matching to take a value of type Person and bind the individual components to the variables age and name which we can then use in the function body.

It’s now possible for our type to be used by functions which care only that they’re given a type with an instance for Show. One such function is print. Its type signature specifies a class constraint to the left of the => allowing the use of show in the function body.

print :: Show a => a -> IO ()
print x = putStrLn (show x)

We could use all of this in a Haskell program like so:

main = print (Person 29 "Pat")

As you might have guessed, this program would print Pat, 29 years old to your terminal.

Renderable

With all that fresh Haskell knowledge, we can now speak to the actual problem at hand.

Using Show as an example, we can define our own type class:

class Render a where
    render :: a -> IO ()

This states that any type a can be made renderable by defining the function render which takes that type as argument and does whatever is required to render it on screen. Much like print, this would be an IO action. The details of IO in Haskell and the actual meaning of IO () are very interesting topics, but well outside the scope of this post.

Presuming we have the types Ball and Player in our system, we can make an instance of Render for each.

data Ball = Ball

instance Render Ball where
    render ball = do
        -- whatever

data Player = Player

instance Render Player where
    render player = do
        -- whatever

By implementing an instance for both types currently in our domain, we can now write functions which don’t care if they’re given a Ball or Player, they simply need something that can be rendered.

renderAll :: Render a => [a] -> IO ()
renderAll rs = mapM_ render rs

We need to use mapM_ here in place of the map you might expect because of the IO involved. This detail can be safely ignored, but I direct any curious readers to the docs.

Let’s test this thing out.

main = do
    -- ...

    renderAll [ball, playerOne, playerTwo]
/home/patrick/test.hs:4:22:
    Couldn't match expected type `Ball' with actual type `Player'
    In the expression: playerOne
    In the first argument of `renderAll', namely `[ball, playerOne, playerTwo]'
    In the expression: renderAll [ball, playerOne, playerTwo]

Uh-Oh.

The Problem

The reason this is an error is because Haskell does not allow heterogeneous lists. In other words, all elements in a list must be of the same type. We might consider this list of game elements as homogeneous because they are all renderable. In a language like Ruby or Java, this code would work fine. In Haskell, we have a much stricter type system and even though these values share an interface, they are not the same type.

This is where my colleague got stuck and asked me the question which sparked this blog post. It is a very common question for those learning a new language to ask those that already know it:

How do I do X in language Y?

In this case, X was “heterogeneous lists” and Y was “Haskell”.

I gave him what is probably the most common response to such questions:

Why on earth do you want to do X?

In actuality, there are a few approaches for doing heterogeneous lists in Haskell. However, I don’t think this is a good use case. We can get around this problem in a cleaner and safer way by using the type system rather than subverting it.

Thinking in Types

A list of a specific type is suitably descriptive, you have many Foos. However, if you find yourself attempting to put objects of different types into a single list you lose any descriptiveness. Even if the language allowed it, all you’d have is a blob of generic things with no sense of what those things represent when taken together.

As one solution to this problem, I would define a type to play the role of what is currently that nondescript list. This adds shape and safety to our program:

data Game = Game Ball Player Player

A Game consists of a Ball and two Players. As a trade-off, we could’ve also specified a Game as a Ball and list of Players. This would be more flexible, but less safe since it would make it possible to create a game with the wrong number of players. Haskell’s type system shines best when you encode as many invariants as possible within the types themselves. It’s impossible to run a Haskell program with a type error, so it follows that any logic encoded in those types is guaranteed correct. This is why we hear that Haskell reprise if it compiles, it works.

While any technique that reduces the possibility of certain bugs is a very real and tangible benefit, moving from a generic list to a more structured type has many other advantages. The code is easier to read and understand when you group data in a structured type rather than an opaque list. We can also extend our system by adding behavior around this data type specifically. Those behaviors will also be easier to understand because their arguments or return values will be of a more structured and well-understood type.

Composite

The next change motivated by this type is turning renderAll into renderGame –but wait– that could just be render:

instance Render Game where
    render (Game b p1 p2) = do
        render b
        render p1
        render p2

main = do
    -- ...

    render game

What we have now is a form of the Composite pattern: a compound value indistinguishable from its individual parts (at least when it comes to rendering). By using type class polymorphism and this composite data type, our system more closely follows Open/Closed and does its best to minimize the impact of the Expression Problem. Extending our game can occur in a number of flexible ways.

For example, we could extend the Game type and its instance with another record of some renderable type:

data Game = Game Ball Player Player Score

instance Render Game where
    render (Game b p1 p2 s) = do
        render b
        render p1
        render p2
        render s

If we’re careful in our module exports, a change like this can be done in a backward-compatible way. Such an approach is outlined here.

If for whatever reason we cannot change Game, we may choose to extend our Composite another layer:

data ExtendedGame = ExtendedGame Game Score

instance Render ExtendedGame where
    render (ExtendedGame g s) = do
        render g
        render s

Hopefully this post has shown that a strong static type system is not some evil thing to be avoided. It can help guide you in designing abstractions and ensure you don’t make mistakes. Languages like Haskell embrace this idea and make it easy to utilize to great effect. I hope you found it as interesting as I did to see how a small shift in thinking can not only work around a “limitation” but also improve the code you write.

What’s next?

  • Interested in learning some Haskell? Start with Learn you a Haskell.
  • Want to learn more about type classes in particular? Check out this talk. Type classes come in around minute 40.

The problem with using fixtures in Rails

Posted 4 months back at interblah.net - Home

I’ve been trying to largely ignore the recent TDD discussion prompted by DHH’s RailsConf 2014 keynote. I think I can understand where he’s coming from, and my only real concern with not sharing his point of view is that it makes it less likely that Rails will be steered in a direction which makes TDD easier. But that’s OK, and my concern grows then I have opportunities to propose improvements.

I don’t even really mind what he’s said in his latest post about unit testing the Basecamp codebase. There are a lot of Rails applications – including ones I’ve written – where a four-minute test suite would’ve been a huge triumph.

I could make some pithy argument like:

Sorry, I couldn't resist

… but let’s be honest, four minutes for a substantial and mature codebase is pretty excellent in the Rails world.

So that is actually pretty cool.

Using fixtures

A lot of that speed is no doubt because Basecamp is using fixtures: test data that is loaded once at the start of the test run, and then reset by wrapping each test in a transaction and rolling back before starting the next test.

This can be a benefit because the alternative – assuming that you want to get some data into the database before your test runs – is to insert all the data required for each test, which can potentially involve a large tree of related models. Doing this hundreds or thousands of times will definitely slow your test suite down.

(Note that for the purposes of my point below, I’m deliberately not considering the option of not hitting the database at all. In reality, that’s what I’d do, but let’s just imagine that it wasn’t an option for a second, yeah? OK, great.)

So, fixtures will probably make the whole test suite faster. Sounds good, right?

The problem with fixtures

I feel like this is glossing over the real problem with fixtures: unless you are using independent fixtures for each test, your shared fixtures have coupled your tests together. Since I’m pretty sure that nobody is actually using independent fixtures for every test, I am going to go out on a limb and just state:

Fixtures have coupled your tests together.

This isn’t a new insight. This is pain that I’ve felt acutely in the past, and was my primary motivation for leaving fixtures behind.

Say you use the same ‘user’ fixture between two tests in different parts of your test suite. Modifying that fixture to respond to a change in one test can now potentially cause the other test to fail, if the assumptions either test was making about its test data are no longer true (e.g. the user should not be admin, the user should only have a short bio, or so on).

If you use fixtures and share them between tests, you’re putting the burden of managing this coupling on yourself or the rest of your development team.

Going back to DHH’s post:

Why on earth would you run your entire test harness for every single line change in a particular model? If you have so little confidence in the locality of your changes, the tests are indeed telling you that the system has overly high coupling.

What fixtures do is introduce overly high coupling in the test suite itself. If you make any change to your fixtures, I do not think it’s possible to be confident that you haven’t broken a single test unless you run the whole suite again.

Fixtures separate the reason test data is like it is from the tests themselves, rather than keeping them close together.

I might be wrong

Now perhaps I have only been exposed to problematic fixtures, and there are techniques for reliably avoiding this coupling or at least managing it better. If that’s the case, then I’d really love to hear more about them.

Or, perhaps the pain of managing fixture coupling is objectively less than the pain of changing the way you write software to both avoid fixtures AND avoid slowing down the test suite by inserting data into the database thousands of times?

That’s certainly possible. I am skeptical though.

Docker-friendly Vagrant boxes 2014-04-30 released

Posted 4 months back at Phusion Corporate Blog

Vagrant

We provide Vagrant base boxes that are based on Ubuntu 14.04 and 12.04, 64-bit. These boxes are specifically customized to work well with Docker. Please learn more at the website

The changes in version 2014-02-30 are:

  • The Ubuntu 12.04 VirtualBox box in release 2014-02-22 was broken: the VirtualBox guest additions weren’t correctly installed because the kernel was incorrectly installed. This has now been fixed.
  • The Ubuntu 12.04 VMWare Fusion box now loads the VMWare Tools kernel modules during startup, so that Vagrant doesn’t have to wait so long at the “Waiting for HGFS kernel module” phase.
  • No changes in the Ubuntu 14.04 boxes.

Related resources: Github | Prebuilt boxes | Vagrant Cloud | Discussion forum | Twitter

Upgrade instructions for Vagrant >= 1.5 with Vagrant Cloud

Run:

vagrant box outdated

Upgrade instructions for Vagrant <= 1.4, or Vagrant >= 1.5 without Vagrant Cloud

Destroy your Vagrant VM:

vagrant destroy

Remove your existing base box:

# Vagrant >= 1.5
vagrant box remove phusion-open-ubuntu-12.04-amd64 --provider virtualbox
vagrant box remove phusion-open-ubuntu-12.04-amd64 --provider vmware_fusion

# Vagrant <= 1.4
vagrant box remove phusion-open-ubuntu-12.04-amd64 virtualbox
vagrant box remove phusion-open-ubuntu-12.04-amd64 vmware_fusion

Start your VM again. Vagrant will automatically download the latest version of the box.

vagrant up

Episode #460 - April 29th, 2014

Posted 4 months back at Ruby5

Configuring variants with Various, what to learn with What's Next, fixing Celluloid with RailsReloader, improving communication with Capistrano Team Notifications, integrating AngularJS with Rails, and getting more from Postgres with PG Power.

Listen to this episode on Ruby5

Sponsored by Pull Review

You want to ship it right instead of doing it again. But what could you clean while still meeting the deadline? PullReview reviews the Ruby code you just wrote and tells you what's wrong, why, and how to fix it - from style to security. Code, Spot, Fix, and Ship!
This episode is sponsored by Pull Review

Various

Various, by Zachary Friedman, is a gem that allows you to easily configure ActionPack::Variants for your Rails apps. The gem allows you to easily configure a mapping of user agent regular expressions which will set the request.variant automatically, based on whether or not there was a match from the User Agent.
Various

What's Next

Matthieu Tanguay-Carel wrote to us about What’s Next, a new micro-site designed to help programmers figure out what to learn at various stages in the learning process. It's got links for beginners and experts, as well as interview questions and a ranking of GitHub repositories.
What's Next

RailsReloader

Brandon Hilkert wrote a blog post on how he used the Rails Reloader to fix an issue on his library, SuckerPunch. He describes diving into Rails` source code, starting at the Reloader middleware. By following the comments found at the top of the Reloader class, he was able to find the solution.
RailsReloader

Capistrano Team Notifications

Alexander Balashov has created a gem which helps track Capistrano deploys via Space notifications and OSX Notification Center. The gem is called capistrano-team_notifications, and it allows everyone on your team to be notified any time a capistrano deploy occurs.
Capistrano Team Notifications

Rails & AngularJS

Sébastien Saunier wrote a blog post on how to integrate AngularJS services to an existing Rails app. He covers integrating Angular with Rails, setting up Karma and Jasmine for testing and making sure they all play nice with the Rails asset pipeline.
Rails & AngularJS

PG Power

Stan Carver wrote to us about PG Power, an ActiveRecord extension that helps to get more from PostgreSQL, like creating and dropping schemas, managing comments, and the ability to add foreign keys.
PG Power

TopRubyJobs

Red Digital Cinema is looking for a Sr. Ruby Software Engineer in Irvine, CA and Houston, TX. EquityMetrix is looking for an Application Developer in Dallas, TX and Science Exchange is looking for a Senior Ruby on Rails Engineer in Palo Alto, CA. If you’re looking for a Top Ruby gig or top ruby talent, head over to TopRubyJobs.com
TopRubyJobs

Thank You for Listening to Ruby5

Ruby5 is released Tuesday and Friday mornings. To stay informed about and active with this podcast, we encourage you to do one of the following:

Thank You for Listening to Ruby5

Announcing the Software Apprenticeship Podcast

Posted 4 months back at Jake Scruggs

In the summer of 2004 I did an apprenticeship of sorts at a place called Object Mentor.  At the time “Uncle” Bob Martin and his son Micah Martin were in leadership positions at the company and I somehow convinced them to let me work for free over the summer in exchange for teaching me software development. It wasn’t a very structured program, nothing like what Micah would later put together for 8th Light, but I was a pretty motivated learner.  I also had the advantage of coming from a teaching background so I knew how to learn.

All this has been covered in daily detail, if you'd like to read more.

After ten years of software experience I’m becoming a mentor to an apprentice and documenting the experience via podcast.  Backstop Solutions has graciously allowed me to pay our apprentice (the same rate we pay interns) as he is doing real work on a daily basis in addition to outside learning experiences.  From 9-5 he will be working on production code with 100% supervision as he will always be pairing with an experienced developer.  It’s a six month program with 2 month check-ins.

The apprentice, Jonathan Howden, knows that should he fail to meet expectations we may end our relationship at 2, 4, or 6 months.  This is a bit scary, but if Backstop is going to be taking a chance on an un-credentialed employee we, as a company, need to be able mitigate the risk of such a person polluting our codebase.  It is therefore our responsibility to provide constant feedback to the apprentice so that he will know exactly what is needed to succeed.  So far he’s been doing great: He just finished his 3rd week of apprenticeship so we just recorded our third podcast and will be on a weekly schedule. Assuming he survives the six month apprenticeship, Jonathan will be offered a full time job at a damn good starting salary.  Interested in such a job right now? Check out https://careers.backstopsolutions.com/

In the first episode, Jonathan talks quite a bit about Dev Bootcamp (DBC).  I’ve known, worked with, and read the book of one of the founders so it seemed natural to reach out to Dave Hoover and DBC to help Backstop find its first apprentice.  We asked their “fairy job mother” to spread the word that we were looking for apprentices and ten applied.  They were all given coding homework challenges which were evaluated code review style with the whole InvestorBridge team allowed to attend.  We judged three submissions good enough to warrant an in-person interview.  Jonathan made it through this gauntlet and was rewarded with a brand new, much longer, gauntlet.  Of learning.  Look, there's no way not to make this sound hokey as we're trying to do a good thing here.

On a weekly basis I hope to capture what an apprenticeship is from the inside and perhaps provide some value to proto-developers and prospective mentor companies who may be wondering what this “apprenticeship” business is all about.  Changing careers is, like it or not, the future.  I did it in 2004 and I hope Jonathan will too in 2014.

Software Apprenticeship Podcast:
iTunes Page: https://itunes.apple.com/us/podcast/software-apprenticeship-podcast/id868371146?mt=2
RSS feed: http://softwareapprenticeship.libsyn.com/rss


Styling a Middleman Blog with Bourbon, Neat, and Bitters

Posted 4 months back at GIANT ROBOTS SMASHING INTO OTHER GIANT ROBOTS - Home

This is a walk-through for styling your own static blog from scratch. We will be using Middleman for our framework and Bourbon, Neat, and Bitters for our Sass libraries.

Middleman is a lightweight static site framework built using Ruby. It compiles Markdown into HTML and is easily deployed to S3, Heroku, or GitHub Pages.

Middleman can also host a blog nicely like this blog.

The following steps will include instructions for installation, setup, deployment, and adding some very basic styles.

Installation

First, we install the Middleman gem and the blog extension gem. We can then initialize the project:

$ gem install middleman-blog
$ middleman init my_blog --template=blog --rack

Let’s start the server and take a look at what we’ve got:

$ cd my_blog
$ bundle exec middleman
$ open http://localhost:4567

You should see something like this in your browser:

Craigslist style

Middleman gives us a default post and just the default styles, which is a great place to start.

Configuration

We’ll be doing a lot of browser refreshing to see our progress, so let’s automate the process. We can use the built-in Livereload service to auto-refresh the page whenever we save. Let’s add the gem:

Gemfile

...
group :development do
  gem 'middleman-livereload'
end

And enable the service by uncommenting the configuration line:

config.rb

...
configure :development do
  activate :livereload
end

Livereload will begin working as soon as you run bundle and restart your server.

$ ctrl + c //shuts down Middleman server
$ bundle
$ bundle exec middleman

Prepare to Deploy

Our blog won’t run on Heroku as-is, but we only need to do a few things to change that.

First, we need to add some code to config.rb that will tell Middleman to put the files Heroku needs in a folder named tmp:

...
set :build_dir, 'tmp'
...

Next, we will create a file that tells Heroku how to build our source files. We will create a file named Rakefile in the root directory of our project and add the code below:

Rakefile

namespace :assets do
  task :precompile do
    sh "middleman build"
  end
end

config.ru

require 'rack/contrib/try_static'

use Rack::Deflater
use Rack::TryStatic,
  root: 'tmp',
  urls: %w[/],
  try: %w[.html index.html /index.html]

FIVE_MINUTES=300

run lambda { |env|
  [
    404,
    {
      'Content-Type'  => 'text/html',
      'Cache-Control' => "public, max-age=#{FIVE_MINUTES}"
    },
    ['File not found']
  ]
}

We’ll also need to include the rack-contrib gem in our Gemfile. Be sure to bundle and restart your server after this step.

Gemfile

...
gem 'rack-contrib'
...

The final step is initializing Git, which we will do next.

Initialize Git

To be able to track our changes and push our blog to Heroku, we need to initialize a Git repo.

$ git init
$ git add .
$ git commit -m 'initial commit'

To commit changes as we continue to work, we’ll run git add . to track new files and stage changes to files already being tracked. Then we can run git commit -m 'your commit message' and we’ll be able to push our latest changes to the remote.

It’s a good idea to commit changes to git at the end of each section of this post.

We’ll be using Heroku as a remote repository.

It would be beneficial to also set up a remote like GitHub for remote version tracking, but it’s not necessary.

We’ll just focus on Heroku for now. If you don’t already have a Heroku account, you’ll need to sign up for one before running heroku create.

$ heroku create
$ git push heroku master

And now, we can run heroku open in the terminal to open the page in our browser. We’ve just created a blog and pushed it live. Next is to add our own styles to customize the design.

Install Libraries

Our goal is to add a custom design to this blog, so let’s install our Sass toolkit and bundle:

Gemfile

gem 'bitters'
gem 'bourbon'
gem 'neat'

Bourbon is a library of vanilla Sass mixins, Neat gives us a responsive grid system, and Bitters sets default styles for Bourbon projects. These gems will make the assets available to our site through Middleman’s asset pipeline.

Since we’ve updated our Gemfile, we’ll need to bundle and restart our server again.

Bourbon and Neat are included by the gem, but Bitters requires an additional install in your stylesheets folder:

$ cd source/stylesheets
$ bitters install
Bitters files installed to /bitters

Next, we need to create a stylesheet manifest with the correct character encoding and import our design libraries:

source/stylesheets/all.css.scss

@charset "utf-8";

@import "bourbon";
@import "bitters/bitters";   /* Bitters needs to be imported before Neat */
@import "neat";

Include all of the stylesheets to be used in this site by adding the link to the manifest in the <head> section of layout.erb:

source/layout.erb

...
<head>
  <%= stylesheet_link_tag "all" %>
...

Let’s see how it looks now:

Bitters default style

Already, we see improvement. What did Bitters just set up for us?

  • Typography - Uses Helvetica as default font-family and sets the sizes for various header elements on a modular scale (e.g. <h1>’s and family)
  • Color - uses variables to systematize colors.
  • Lists - strips all styles from lists including bullets
  • Flash notice styles - very useful in Rails
  • Grid settings to accompany Neat
  • Some basic form styles

Get Stylish

We’ll need to customize a few things in Bitters to optimize our styles for a blog. First, let’s add our own Google font to layout.erb:

source/layout.erb

<head>
...
<link href='http://fonts.googleapis.com/css?family=Oxygen:400,300,700'
  rel='stylesheet' type='text/css'>
...
</head>

To make use of this font, all we need to do is change the $sans-serif variable in _variables.scss:

source/stylesheets/bitters/_variables.scss

...
$sans-serif: 'Oxygen', $helvetica;
...

By changing the $sans-serif variable, we’ve quickly and easily changed the font family globally.

Comfortable Reading

Let’s create a partial that will contain all of the layout related styles. We’ll need to import it in our manifest:

source/stylesheets/all.css.scss

...
@import "partials/layout";

Add the outer-container() mixin to the layout to center it in the viewport.

source/stylesheets/partials/_layout.scss

#main {
    @include outer-container;
}

For a good reading experience, we want to keep the length of the lines of text a comfortable length. If the lines are too long, the reader will have a hard time following the flow of the text.

Neat makes this easy to accomplish in as little as two steps. We’ll adjust the max-width property of the outer-container() mixin.

The first step will be to import _grid-settings.scss into Bitters. We’ll can just uncomment that line in _bitters.scss:

source/stylesheets/bitters/_bitters.scss

...
@import "grid-settings";

The second step is to edit _grid-settings.scss. Uncomment the $max-width variable and change its value to em(700). This should give us a comfortable line-length for reading.

source/stylesheets/_grid-settings.scss

...
$max-width: em(700);
...

Let’s see what our blog looks like now that we’ve added a few styles of our own:

Custom grid-settings

We see that Bitters has successfully applied our chosen font and centered our content. Don’t worry about some of the content being misaligned. We’re about to fix that.

Modular Structure

Our readers need to be able to easily move around the site, so we’ll add some helpful links in a navigation and footer.

To keep our code modular, we will break up the navigation and footer into separate partials. It’s good practice to make a folder to keep your partials in.

We’ll edit a group of new files:

  source/partials/_nav.erb
  source/partials/_footer.erb

  source/stylesheets/partials/_nav.scss
  source/stylesheets/partials/_footer.scss

Now that we’ve added some structure to our code we can import these partials into layout.erb and our Sass partials into all.css.scss.

source/layout.erb

...
<div id="main" role="main">
  <%= partial "partials/nav" %>
  <%= yield %>
  <%= partial "partials/footer" %>
</div>
...

Improved Markup

We are ready to improve the overall layout of our index page. A few small adjustments to the markup will make it more semantic and easier to style.

Paste the code below into _nav.erb:

source/_nav.erb

<nav>
  <ul>
    <li>
      <%= link_to "Blog Title", "index.html", :class => 'blog-title' %>
    </li>
  </ul>
</nav>

We will move some of the content from layout.erb into the footer. Paste the code below into _footer.erb and remove it from layout.erb:

source/_footer.erb

<footer>
  <ul class="large-column">
    <li><h5 class="heading">Recent Articles</h5></li>
    <li>
      <ol>
        <% blog.articles[0...10].each do |article| %>
          <li>
            <%= link_to article.title, article %>
            <span><%= article.date.strftime('%b %e') %></span>
          </li>
        <% end %>
      </ol>
    </li>
  </ul>

  <ul class="small-column">
    <li><h5 class="heading">Tags</h5></li>
    <li>
      <ol>
        <% blog.tags.each do |tag, articles| %>
          <li><%= link_to "#{tag} (#{articles.size})", tag_path(tag) %></li>
        <% end %>
      </ol>
    </li>
  <ul>
</footer>

Additionally, we’ll improve the markup in index.html.erb:

source/index.html.erb

...
<ul>
  <% page_articles.each_with_index do |article, i| %>
    <li>
      <h3><%= link_to article.title, article %></h3>
      <h5><%= article.date.strftime('%b %e') %></h5>
      <p><%= article.body %></p>
    </li>
  <% end %>
</ul>
...

Adding Custom Styles

As a finishing touch, we’ll add some custom styles to our navigation, footer, and layout: For consistency, we will also create Sass partials for the nav and the footer.

source/stylesheets/all.css.scss

...
@import "partials/nav";
@import "partials/footer";

source/stylesheets/partials/_nav.scss

nav {
  border-bottom: 1px solid $base-border-color;
  margin: em(30) 0;

  ul {
    display: inline-block;
    margin-bottom: em(10);
  }
}

.blog-title {
  font-size: 1.4em;
  font-weight: 700;
  letterspacing: 4px;
  text-transform: uppercase;
}

source/stylesheets/partials/_footer.scss

footer {
  border-top: 1px solid $base-border-color;
  margin: 2em 0;
  padding-top: 2em;
}

Some styles are providing a style pattern we’ll use throughout the blog. We’ll place these styles in the _layout.scss stylesheet since they create a reusable layout pattern.

source/stylesheets/partials/_layout.scss

...
ol {
  font-size: 1em;
  font-weight: 500;

  li {
    margin: .5em 0;

    span {
      display: inline-block;

      &:before {
        content: '/';
        margin: 0 .3em;
      }
    }
  }
}
...

Using the mixin @include span-columns(), Neat will calculate the width of the div based on the number of columns you specify in the argument.

source/stylesheets/partials/_layout.scss

...
.large-column {
  @include span-columns(8 of 12);
}

.small-column {
  @include span-columns(4 of 12);
}

Now we have a basic template set up for our very own blog.

Final Results

All that’s left to do is make sure all of our changes have been committed to Git and then deploy these updates to Heroku.

$ git push heroku master

Completion

Now we have a good foundation upon which to publish our own blog.

We Are All Wrong About Software Design

Posted 4 months back at Luca Guidi - Home

We are all wrong. When it comes to talk about opinions this is the way that things work. Everyone has her or his own beliefs shaped by years of experience in the field, frustrating code, books, successes, etc. How can all these backgrounds fall into a one unified theory? They just can’t.

You’ve always been told to pick the right tool for the job. But what’s the right tool? You decide it, according to your practical knowledge.

I love Ruby because I feel it natural, but other developers hate this language. I prefer clean code, other people don’t care. I’m for RSpec and Capybara, other for Test::Unit. CoffeeScript vs plain JavaScript, ERb vs HAML, Postgres vs MySQL. Vim or Emacs? Mac or Linux? TDD or not, anyone?

With all these partitions, we’re not freeing people from dogmas, but just creating fans of an opposite opinion.

Relativity can be applied to software design as well. How many levels of indirection do I need to get a certain job done? Well, it depends. It depends on a myriad of good reasons, but mainly on your judgement. Which can be superior for you, and fallacious for somebody else.

We can discuss about tradeoffs, but please stop using your successful product as the certification that you’re right about code.

I work at Litmus, a profitable company. If I’d put the following code in a template, do you will find it reasonable just because of my employer?

<%
  require 'mysql2'

  client = Mysql2::Client.new({
    host: 'host',
    username: 'username',
    database: 'database'})

  rows = client.query(%{SELECT * FROM previews
    ORDER BY created_at DESC
    LIMIT 5})
%>

<ul>
<% rows.each do |row| %>
  <li><%= row.fetch(:title) %></li>
<% end %>
</ul>

Hey, it works! Who needs all those fancy abstractions like controllers and ORMs. Who needs frameworks at all! That constructs are for architecture astronauts. Get off my lawn! Look at me, I’m a pragmatist. I proved this by ruining the multi-millionaire software I work on.

This isn’t an argument, just nonsense.

Episode #459 - April 25th, 2014

Posted 4 months back at Ruby5

A web interface for letter_opener, getting right at your Mint.com data, observers in mongoid 4, an interview with DHH, parsing out social network user ids, and the Ruby Hero Awards all in this episode of the Ruby5!

Listen to this episode on Ruby5

Sponsored by New Relic

New Relic is _the_ all-in-one web performance analytics product. It lets you manage and monitor web application performance, from the browser down to the line of code. With Real User Monitoring, New Relic users can see browser response times by geographical location of the user, or by browser type.
This episode is sponsored by New Relic

letter_opener_web

Add a web interface to letter_opener in development with letter_opener_web.
letter_opener_web

mint-exporter

Export your Mint.com transactions with Ruby!
mint-exporter

mongoid-observers

Mongoid 4 comes with the removal of observers. Thanks to Chamnap Chhorn though, we won't have to rewrite our apps depending on them!
mongoid-observers

Interview with DHH

Chat with DHH about nuance, where he stands with TDD today, increasing the bandwidth of conversations and his thoughts on how F/OSS software is used by for-profit corporations
Interview with DHH

ids_please

Please, please, please give me all your IDs! The ids_please gem can parse out user ids from all your favorite social network urls.
ids_please

Ruby Heroes 2014

The 2014 Ruby Heroes have been announced!
Ruby Heroes 2014

Open Cube: Making publishing statistics easier

Posted 4 months back at RicRoberts :

Open Cube logo

We’ve recently started work on another European collaborative project called OpenCube. This project is all about making open statistical data easier to publish, link and reuse so it can reach its full potential. The technical approach concentrates on the RDF Data Cube vocabulary, that recently reached W3C recommendation status.

This project is very relevant to our work: much of the data that our customers publish using PublishMyData is statistical data and we are big users of the RDF Data Cube approach. We can already see the power of this approach: for example how it enables combining datasets together, as in our Stats Selector tool. But we also have first hand experience of the challenges our customers face in creating RDF Data Cube data and can see many further opportunities for enriching access to data in this form.

A real strength of OpenCube is the close involvement of a group of ‘use case partners’. These are organisations that have agreed to participate in a series of pilot studies, assisting us with setting the requirements of the project and evaluating the tools we create. The pilots will involve the UK Department for Communities and Local Government, the Government of Flanders, the Irish Central Statistics Office and a (yet to be confirmed) Swiss bank.

As part of the project we’ll be creating an OpenCube extension of PublishMyData. This extension will include lots of cool stuff including:

  • tools for transforming CSV files and Excel spreadsheets to RDF Data Cube datasets (without the need for programming)
  • tools for managing a collection of concept schemes
  • tools for selecting URIs from external reference data
  • quality checks that make sure any generated RDF meets the required standards

So, like the DaPaaS project, we’re excited about being part of this because it will help us make Linked Data easier to create and easier to exploit; bringing the benefits to a larger community of users.

Again, we’re lucky to be working alongside some great data people on this project. Take a look at the links below to find out more about who’s involved:

Is Ruby Manor X happening this year?

Posted 4 months back at interblah.net - Home

It’s been almost six years since the first Ruby Manor. Last year we ran Ruby Manor 4.

The observant among you will notice that four conferences into six years leaves some years where a Ruby Manor did not happen. However, it might not be obvious why this is the case.

I’ve already written at length here about why Ruby Manor is a conference, just not a traditional one. With each iteration of the event, we have tried to stay true to the manifesto while making careful changes to see if we can improve on the previous event.

As I’ve said before, the right way to think about Ruby Manor is as an experiment. We make hypotheses (e.g. ‘community feedback during the proposal process will result in more relevant presentations’ or ‘not spending money on t-shirts will not detract from the conference experience’), then we run the experiment and evaluate the results.

In most cases the experiment has been largely successful. I’m pretty sure most people who’ve come to one or more Ruby Manors have enjoyed the day, enjoyed the majority of the content, enjoyed not having to spend hundreds of pounds or dollars, not minded the lack of swag and so on. It’s probably true to say that we could run a basically similar event ever year, and most people would be largely happy.

However – and here I speak mainly for myself, although I know that Murray and Tom feel largely similarly – I’m not desperately interested in putting bums-on-seats once per solar revolution, just for the sake of it.

I don’t know what the next experiment is.

Introducing Lotus::Model

Posted 4 months back at Luca Guidi - Home

Almost all the Ruby frameworks for the Model layer mix up business logic with database details. This kind of architecture leads to god classes, slow build times and to a general bad design. These problems are well known to legacy projects’s maintainers.

What if we assign these roles to smaller components that are able to collaborate together? Imagine how life changing would be to work just with objects, without worrying how to persist them. How easy and fast would be testing them? How small and well defined would be your objects?

Let me introduce Lotus::Model.

It brings a new level of decoupling that is a huge step in that direction. The framework constitutes a boundary that offers a convenient public API to execute queries and commands to persist and fetch entities.

Entities

An entity is the core of an application, where the part of the domain logic is implemented. It’s a small, cohesive object that express coherent and meaningful behaviors.

It deals with one and only one responsibility that is pertinent to the domain of the application, without caring about details such as persistence or validations.

This simplicity of design allows you to focus on behaviors, or message passing if you will, which is the quintessence of Object Oriented Programming.

Consider this object:

class Article
  attr_accessor :id, :title, :text

  def initialize(attributes = {})
    @id, @title, @text =
      attributes.values_at(:id, :title, :text)
  end
end

It can be optionally expressed as:

require 'lotus/model'

class Article
  include Lotus::Entity
  self.attributes = :title, :text
end

Yes, optionally. Lotus::Model can work with pure objects, as long they implement that small interface above.

But how the framework knows how to handle these objects?

Data Mapper

We use a data mapper for the job. It’s a persistence mapper that keep entities unaware of schema details. Good news are that it’s database independent, it can work with SQL, document, and even with key/value stores.

The role of a data mapper is to translate database columns into the corresponding attribute of an entity.

require 'lotus/model'

mapper = Lotus::Model::Mapper.new do
  collection :articles do
    entity Article

    attribute :id,    Integer
    attribute :title, String
    attribute :text,  String
  end
end

For simplicity sake, imagine that the mapper above is used with a SQL database. We use #collection to indicate the table that we want to map, #entity to indicate the kind of object to persist. In the end, each #attribute call specifies which Ruby type we want to associate for given column.

Repositories

Once we have in place all the entities and a mapping for them, we can use a repository to talk with a database.

A repository is an object that mediates between entites and the persistence layer. It offers a standardized API to query and execute commands on a database.

A repository is storage idenpendent, all the queries and commands are delegated to the current adapter.

This architecture has several advantages:

* An application depends on an standard API, instead of low level details (Dependency Inversion principle)

* An application depends on a stable API, that doesn’t change if the storage changes

* You can postpone storage decisions

* It confines persistence logic at a low level

* Multiple data sources can easily coexist in an application

require 'lotus/model'

class ArticleRepository
  include Lotus::Repository
end

When a class includes Lotus::Repository it will expose CRUD methods such as .create, .update, .find, and a powerful private query API. This decision forces developers to define intention revealing APIs, instead leak storage details outside of a repository.

Look at the following code:

ArticleRepository.
  where(author_id: 23).
  order(:published_at).
  limit(8)

This is an example of implicit API, it means nothing in terms of the behavior of the domain model. It’s just a chain of method calls, from the caller, that should be aware of the internal query mechanisms.

There is a better way to write it:

require 'lotus/model'

class ArticleRepository
  include Lotus::Repository

  def self.most_recent_by_author(author, limit = 8)
    query do
      where(author_id: author.id).
        order(:published_at)
    end.limit(limit)
  end
end

Look at how revealing is the name of that method. It encapsulates the implementation details, in favor of a clear and testable API.

If we change the type of database, the callers of that method will be unaffected.

Adapters

As mentioned above, Lotus::Model is database agnostic. A repository forwards method calls to its current adapter. An adapter is a concrete implementation of persistence logic for a specific database. The framework is shipped with two adapters:

* SqlAdapter * MemoryAdapter

An adapter can be associated to one or multiple repositories and different repositories can have different data sources. For instance an application can have ArticleAdapter that uses a SQL database and TweetRepository that talks to a third part JSON service.

Roadmap

For the next two months, I will focus on Lotus (the gem). The main goal is to make all the frameworks to work together in a full stack app. This will require improve the existing libraries and empower them with the missing features.

On June 23rd I will release Lotus.

To stay updated with the latest releases, to receive code examples, implementation details and announcements, please consider to subscribe to the Lotus mailing list.

<link href="//cdn-images.mailchimp.com/embedcode/slim-081711.css" rel="stylesheet" type="text/css"/>

Episode #458 - April 22nd, 2014

Posted 4 months back at Ruby5

This week we cover Searchlight's 3.0, dumping code in models, this week in Rails commits, Whiny Validations, Bootstrap 3 support for Simple Form, and how to be an open source gardener.

Listen to this episode on Ruby5

Sponsored by Top Ruby Jobs

If you're looking for a top Ruby job or for top Ruby talent, then you should check out Top Ruby Jobs. Top Ruby Jobs is a website dedicated to the best jobs available in the Ruby community.
This episode is sponsored by Top Ruby Jobs

Searchlight 3.0 released

Nathan Long dropped us an email recently to let us know about the 3.0 release of searchlight library, which we originally covered about a year ago now. Searchlight gives you a low-magic way to build database searches. It allows you to encapsulate your search options in an object which is more testable and database agnostic. It also plays really well with Rails forms, so if you find yourself building an advanced search page check it out.
Searchlight 3.0 released

Don’t just dump code into your models

Jakub Arnold of Sensible.io has an interesting post where he takes you through the consequences of dumping coupled code that depends on the Mailchimp gem inside of an ActiveRecord model’s callback cycle. As Jakub explains, this dependency may cause exceptions when saving the model and even if you handle the exception, your call to Mailchimp may fail. He goes through several steps, eventually extracting the Mailchimp logic into a separate class, and to handle possible network issues, he uses a queue which will retry in case of failure. It’s a nice, short example of something that can definitely bite you if you casually take dumps it inside of a Rails model.
Don’t just dump code into your models

This week in Rails

A few weeks ago Godfrey Chan started a new weekly newsletter called this week in Rails, where he’s covering the most interesting commits, pull requests on the Rails code base. In his most recent newsletter he mentioned a commit that introduced a new helper called “sanitize_sql_like” to help escape characters with special meaning in a LIKE clause, another that added a `to_io` method to `UploadedFile`which allows you to directly manipulate a uploaded (temp) file, and a bunch of fixes including getting rid of the wrapping divs on hidden form fields and some optimizations to the postgreSQL adapter. If you enjoy living on the edge of rails, this could be a great weekly newsletter to subscribe to.
This week in Rails

Whiny Validation

Sometimes when you run a spec on a Rails app, it fails silently but it isn’t clear why.. It could be a validation error, but the log may not even tell you that. This is a problem Brian Morearty set out to solve with his Whiny Validation gem, which adds a log message so when you debug you’ll know why your test failed. co: That sounds useful, but this sounds like a pretty simple gem... Yeah, admittedly this is a simple gem. But often enough, simple gems like this end up being merged into Rails when people realize they’re lightweight enough and make so much sense. What’s also great is that Brian wrote a blog post which walks us through the internals of developing the gem, how to use ActiveSupport notifications, and how to add your own Log Subscriber. co: It’s great to have the confidence to get in under the hood of these libraries when you need to, and simple examples can go a long way.
Whiny Validation

Bootstrap 3 Support for Simple Form

It’s been a while on the podcast since we’ve talked about Simple Form, which just this week received support for Bootstrap 3. Simple Form is the gem by plataformatec which gives your Rails app a fully featured DSL for creating form elements. It can be especially useful when you have complex forms which may be stored across multiple models. Aside from adding support for Bootstrap 3, the 3.1 RC1 version of Simple Form which was just released has a bunch of improvements, you can read about in the changelog.
Bootstrap 3 Support for Simple Form

How to be an open source gardener

Steve Klabnik wrote a great piece called How to be an open source gardener in which he talks about his experience working on Rails issue triaging. Everyone who uses Rails — or any open source project really — should give this a read. Steve does a good job to show that open source often involves hard tedious and not so creative work and I really love the gardening analogy. For a beautiful project to keep growing healthily we need people to pull the weeds out, so please check out Richard Schneeman’s CodeTriage and pick an open source project you’d like to occasionally help with issue triaging.
How to be an open source gardener

Sponsored by Ruby5

Ruby5 is released Tuesday and Friday mornings. To stay informed about and active with this podcast, we encourage you to do one of the following:

Thank You for Listening to Ruby5

Sass's @content Directive Use Cases

Posted 4 months back at GIANT ROBOTS SMASHING INTO OTHER GIANT ROBOTS - Home

Sass 3.2 added the @content directive, which allows us to pass a content block into a mixin.

@mixin apply-to-ie6-only {
  * html {
    @content
  }
}

@include apply-to-ie6-only {
  #logo {
    background-image: url(/logo.gif);
  }
}

Generates:

* html #logo {
  background-image: url(/logo.gif);
}

We can use it anywhere that declarations need to be wrapped in outer-scoped selectors, and many places where declarations are duplicated.

Media Queries

We can inline our media queries rather than maintaining separate, device-specific stylesheets, but writing queries over and over can get pretty unwieldy. We can simplify them by passing a content block into a mixin that wraps a query.

@mixin media($width) {
  @media only screen and (max-width: $width) {
    @content;
  }
}

@include media(320px) {
  background: red;
}

Generates:

@media only screen and (max-width: 320px) {
  background: red;
}

This becomes especially helpful for long, highly specific media queries, like the HiDPI mixin we use in Bourbon.

You can see our full @media mixin in Neat.

Keyframes

Keyframes are a good example of content duplication. Rather than rewriting the declarations for each vendor-specific selector, we can instead write a mixin to do it for us.

@mixin keyframes($name) {
  @-webkit-keyframes #{$name} {
    @content;
  }

  @-moz-keyframes #{$name} {
    @content;
  }

  @keyframes #{$name} {
    @content;
  }
}

@include keyframes(fadeIn) {
  from {
    opacity: 0%;
  }
  to {
    opacity: 100%;
  }
}

Generates:

@-webkit-keyframes fadeIn {
  from {
    opacity: 0%;
  }
  to {
    opacity: 100%;
  }
}

@-moz-keyframes fadeIn {
  from {
    opacity: 0%;
  }
  to {
    opacity: 100%;
  }
}

@keyframes fadeIn {
  from {
    opacity: 0%;
  }
  to {
    opacity: 100%;
  }
}

This is also used in Bourbon.

Context Specificity

I just picked up a project from Reda Lemeden, who wrote a pair of clever mixins to modify components for a given context.

Instead of creating many .component--modifiers or chaining modifying classes, we can better separate our concerns by defining a style's context specificity.

@mixin create-context($classes...) {
  @each $class in $classes {
    .#{$class} & {
      @content;
  }
}

@mixin context--alternate-template {
  @include create-context(about, blog) {
    @content
  }
}

.header {
  height: 12em;
  background: red;

  @include context--alternate-template {
    background: green;
  }
}

Generates:

  .header {
    height: 12em;
    background: red;
  }

  .about .header {
    background: green;
  }

  .blog .header {
    background: green;
  }

Getting BEMy

Sass 3.3 adds the @at-root directive and improved &s. The former allows us to nest declarations in Sass, but compile them to the stylesheet's root. The latter appends any following text directly to the parent's selector.

These can be used with @content to simplify writing BEM syntax. Thanks to Scott Kellum for the original implementation.

@mixin element($name) {
  @at-root #{&}__#{$name} {
    @content;
  }
}

@mixin modifier($name) {
  @at-root #{&}--#{$name} {
    @content;
  }
}

.block {
  color: red;

  @include element(element) {
    color: green;

    @include modifier(modifier) {
      color: blue;
    }
  }
}

Generates:

.block {
  color: red;
}

.block__element {
  color: green;
}

.block__element--modifier {
  color: blue;
}

In Conclusion

@content is just one of many Sass directives that can empower us to remove duplication in our SCSS, and think more creatively about its organization and implementation. Learn more by reading the Sass directives documentation.

Uplink Latency of WiFi and 4G Networks

Posted 4 months back at igvita.com

The user opens your application on their device and triggers an action requiring that we fetch a remote resource: application invokes the appropriate platform API (e.g. XMLHttpRequest), the runtime serializes the request (e.g. translates it to a well-formed HTTP request) and passes the resulting byte buffer to the OS, which then fragments it into one or more TCP packets and finally passes the buffer to the link layer.

So far, so good, but what happens next? As you can guess, the answer depends on the properties of the current link layer in use on the device. Let's dig a bit deeper...

Transmitting over WiFi

If the user is on WiFi, then the link layer breaks up the data into multiple frames and (optimistically) begins transmitting data one frame at a time: it waits until the radio channel is "silent," transmits the WiFi frame, and then waits for an acknowledgement from the receiver before proceeding with transmission of the next frame. Yes, you've read that right, each frame requires a full roundtrip between the sender and receiver! 802.11n is the first standard to introduce "frame aggregation," which allows multiple frames to be sent in a single transmission.

Of course, not all transmissions will succeed on their first attempt. If two peers transmit at the same time and on the same channel then a collision will happen and both peers will have to retransmit data: both peers sleep for a random interval and then repeat the process. The WiFi access model is simple to understand and implement, but as you can guess, also doesn't provide any guarantees about the latency costs of the transmission. If the network is mostly idle, then transmission times are nice and low, but if the network is congested, then all bets are off.

In fact, don't be surprised to see 100ms+ delays just for the first hop between the WiFi sender and the access point - e.g. see the histogram above, showing 180ms+ first-hop latency tails on my own (home) WiFi network. That said, note that there is no "typical" or "average" uplink WiFi latency: the latency will depend on the conditions and load of the particular WiFi network. In short, expect high variability and long latency tails, with an occasional chance of network collapse if too many peers are competing for access.

If your WiFi access point is also your gateway then you can run a simple ping command to measure your first hop latency.

Uplink scheduling on 4G networks

In order to make better use of the limited capacity of the shared radio channel and optimize energy use on the device, 4G/LTE standards take a much more hands-on approach to scheduling and resource assignment: the radio tower (eNodeB) notifies the device for when it should listen for inbound data, and also tells the device when it is allowed to transmit data. As you can imagine, this can incur a lot of coordination overhead (read, latency), but such is the cost of achieving higher channel and energy efficiency.

  1. The radio network has a dedicated Physical Uplink Control Channel (PUCCH) which is used by the device to notify the radio network that it wants to transmit data: each device has a periodic timeslot (typically on a 5, 10, or 20 ms interval) where it is allowed to send a Scheduling Request (SR) that consists of a single bit indicating that it needs uplink access.

  2. The SR request bit is received by the radio tower (eNodeB) but the SR request on its own is not sufficient to assign uplink resources as it doesn't tell the scheduler the amount of data that the device intends to transfer. So, the eNodeB responds with a small "uplink grant" that is just large enough to communicate the size of the pending buffer.

  3. Once the device receives its first uplink grant, it waits for its turn to transmit (up to ~5 ms), and sends a Buffer Status Report (BSR) indicating the amount of application data pending in its upload buffers. Finally, the eNodeB receives the BSR message, allocates the necessary uplink resources and sends back another uplink grant that will allow the device to drain its buffer.

What happens if additional data is added to the device buffer while the above process is underway? Simple, the device sends another BSR message and waits for new uplink grant! If timed correctly, then the BSR requests and uplink grants can be pipelined with existing data transfers from the device, allowing us to minimize first-hop delays. On the other hand, once the device buffer is drained and then new data arrives, the entire process is repeated once over: SR, uplink grant, BSR, uplink grant, data transmission.

So, what does this all mean in practice? Let's do the math:

  • If the network is configured to use a 10 ms periodic interval for communicating SR messages then we would expect a ~5 ms average delay before the SR request is sent.
  • There are two full roundtrips between the device and the eNodeB to negotiate the uplink resource assignment to transmit pending application data. The latency incurred by these roundtrips will vary for each network, but as a rule of thumb each exchange is ~5 ms.

Add it all up, and we're looking at 20+ ms of delay between application data arriving at the (empty buffer) of the link layer on the device and the same data being available at the link layer of the eNodeB. From there the packet needs to traverse the carrier network, exit onto the public network, and get routed to your server.

Above uplink latency overhead is one reason why low latency applications, such as delivering voice, can be a big challenge over 4G networks. In fact, for voice specifically, there is ongoing work on Voice over LTE (VoLTE) which aims to address this problem. How? Well, one way is to provide a persistent uplink grant: transmit up to X bytes on a Y periodic interval. Believe it or not, today most 4G networks still fall back to old 3G infrastructure to transmit voice!

Optimizing for WiFi and 4G networks

As you can tell, both WiFi and 4G have their challenges. WiFi can deliver low latency first hop if the network is mostly idle: no coordination is required and the device can transmit whenever it senses that the radio channel is idle. On the other hand, WiFi is subject to high variability and long latency tails if the network has many peers competing for access - and most networks do.

By contrast, 4G networks require coordination between the device and the radio tower for each uplink transfer, which translates to higher minimum latency, but the upside is that 4G can reign in the latency tails and provides more predictable performance and reduces congestion.

So, how does all this impact application developers? First off, latency aside, and regardless of wireless technology, consider the energy costs of your network transfers! Periodic transfers incur high energy overhead due to the need to wake up the radio on each transmission. Second, same periodic transfers also incur high uplink coordination overhead - 4G in particular. In short, don't trickle data. Aggregate your network requests and fire them in one batch: you will reduce energy costs and reduce latency by amortizing scheduling overhead.
