Three Things To Know About Composition

Posted about 1 month back at Luca Guidi - Home

A few days ago Aaron Patterson wrote a in interesting article about composition vs inheritance with Ruby.

He says that when inheriting our classes directly from Ruby’s core objects such as Array, our public API for that object will become too large and difficult to maintain.

Consider a powerful object like String which has 164 public methods, once our library will be released, we should maintain all that amount of code. It doesn’t worth the trouble, probably because we just wanted to pick a few methods from it. It’s better to compose an object that hides all that complexity derived from String, and to expose only the wanted behaviors.

I was already aware of these issues, but that article was a reminder for fixing my OSS projects. For this reason I refactored Lotus::Utils::LoadPaths. It used to inherit from Array (169 methods), but after breaking the inheritance structure, I discovered that I only needed 2 methods.

However, there are some hidden corners that are worthing to share.

Information escape

A characteristic that I want for LoadPaths is the ability to add paths to it. After the refactoring, for the sake of consistency, I decided to name this method after Array’s #push, and to mimic its behavior.

The initial implementation of this method was:

it 'returns self so multiple operations can be performed' do
  paths = Lotus::Utils::LoadPaths.new

  paths.push('..').
        push('../..')

  paths.must_include '..'
  paths.must_include '../..'
end

class Lotus::Utils::LoadPaths
  # ...

  def push(*paths)
    @paths.push(*paths)
  end
end

When we use this Ruby’s method, the returning value is the array itself, because language’s designers wanted to make chainable calls possible. If we look at the implementation of our method, the implicit returning value was @paths (instead of self), so the subsequent invocations were directly manipulating @paths.

The test above was passing because arrays are referenced by their memory address, so that the changes that happened on the outside (after the accidental escape) were also visible by the wrapping object (LoadPaths). Because our main goal is to encapsulate that object, we want to prevent situations like this.

it 'returns self so multiple operations can be performed' do
  paths = Lotus::Utils::LoadPaths.new

  returning = paths.push('.')
  returning.must_be_same_as(paths)

  paths.push('..').
        push('../..')

  paths.must_include '.'
  paths.must_include '..'
  paths.must_include '../..'
end

class Lotus::Utils::LoadPaths
  # ...

  def push(*paths)
    @paths.push(*paths)
    self
  end
end

Dup and Clone

LoadPaths is used by other Lotus libraries, such as Lotus::View. This framework can be “duplicated” with the goal of ease a microservices architecture, where a developer can define MyApp::Web::View and MyApp::Api::View as “copies” of Lotus::View, that can independently coexist in the same Ruby process. In other, words the configurations of one “copy” shouldn’t be propagated to the others.

Until LoadPaths was inheriting from Array, a simple call to #dup was enough to get a fresh, decoupled copy of the same data. Now the object is duplicated but not the variables that it encapsulates (@paths).

paths1 = Lotus::Utils::LoadPaths.new
paths2 = paths1.dup

paths2.push '..'
paths1.include?('..') # => true, which is an unwanted result

The reason of this failure is the same of the information escaping problem: we’re referencing the same array. Ruby has a special method callback that is designed for cases like this.

class Lotus::Utils::LoadPaths
  # ...

  def initialize_copy(original)
    @paths = original.instance_variable_get(:@paths).dup
  end
end

Now, when paths1.dup is called, also the @paths instance variable will be duplicated and we can safely change paths2 without affecting it.

Freeze

A similar problem arises for #freeze. I want Lotus::View to freeze its configurations after the application is loaded. This immutability will prevent accidental changes that may lead to software defects.

When we try to alter the state of a frozen object, Ruby raises a RuntimeError, but this wasn’t the case of LoadPaths.

paths = Lotus::Utils::LoadPaths.new
paths.freeze
paths.frozen? # => true

paths.push '.' # => It wasn't raising RuntimeError

This had an easy fix:

class Lotus::Utils::LoadPaths
  # ...

  def freeze
    super
    @paths.freeze
  end
end

Conclusion

Composition should be preferred over inheritance, but beware of the unexpected behaviors.

I discovered these problems in a matter of a minutes, because the client code of this object (Lotus::View) has some integration tests that are asserting all these features, without assuming anything of the underlying objects. For instance, it checks one by one all the attributes of a configuration after its duplication, without trusting the fact they can safely duplicate themselves. This double layered testing strategy is fundamental for me while building Lotus.

Testing from the Outside-In

Posted about 1 month back at GIANT ROBOTS SMASHING INTO OTHER GIANT ROBOTS - Home

A few months ago my colleague Josh Steiner wrote a comprehensive post on How We Test Rails Applications, detailing the different types tests we write and the various technologies that go with them. In this follow up, we will take a closer look at thoughtbot’s testing workflow.

We use a process known as “Outside-in testing”, driving our development from high-level tests and working our way down to lower-level concerns. Say we are working on an e-commerce site and want to implement the following story:

As a guest, I can add items to my shopping cart so that I can keep on shopping

Before we start thinking about models, controllers, or other architectural concerns we write a high-level RSpec feature test that describes the behavior from the user’s perspective.

# spec/features/guest_adds items_to_shopping_cart_spec.rb
feature 'Guest adds items to shopping cart' do
  scenario 'via search' do
    item = create(:item)

    visit root_path
    fill_in 'Search', with: item.name
    click_on 'Search Catalogue'

    click_on item.name
    click_on 'Add to Cart'
    click_on 'Shopping Cart'

    expect(page).to have_content(item.name)
    expect(page).to have_content("Subtotal: #{item.price})
  end
end

Depending on how much of the application is implemented, this test could break in multiple places. If this were a newly-generated application we might need to implement a home page. Once we have a home page we would probably get an error while attempting to use the search bar saying that ‘No such route exists’. This leads us to implement a /items route.

# config/routes.rb
# ...
resources :items, only: [:index]
# ...

The next few errors walk us through creating an ItemsController, with an empty index action and corresponding view. Now that we can successfully click on “Search Catalogue”, we get an error saying that there the desired item does not appear in the search results so we expose some items in the controller and display them in the view.

# app/controllers/items_controller.rb
#...
def index
  @items = Item.search(params[:search_query])
end
#...
# app/views/items/index.html.erb
<% @items.each do |item| %>
  <%= link_to item.name, item %>
<% end %>

This gives us a new error saying that there is no method search defined Item. At this point, we drop down a level of abstraction and write a unit test for Item.

# spec/models/item_spec.rb
describe Item, '.search' do
  it 'filters items by the search term' do
    desired_item = create(:item)
    other_item = create(:item)

    expect(Item.search(item.name)).to eq [item]
  end
end

This test leads us to correctly implement Item.search:

# app/models/item.rb
#...
def self.search(term)
  where(name: term)
end
#...

Now the unit test passes so we go back up to our feature test. We can successfully click on the item’s name in the search results!

We keep following this pattern for the remaining test failures, dropping down to the unit test level when necessary, until we have a green test suite. Now our story has been successfuly implemented!

Mocking and Stubbing

The goal of a feature test is to test the real system from end-to-end from the user’s perspective. To do this, we use real database records and don’t mock or stub any of our objects. We do stub calls to external websites (via webmock or a fake) since the network can be unreliable. Our tests should run without an internet connection.

When dropping down to the unit test level, we aggressivly mock/stub out dependencies and collaborators. The goal of a unit test is to prove the functionality of the object being tested, not the functionality of its collaborators. Difficulty in testing two objects in isolation from each other often points to too tight coupling between them.

Further Reading

For some more great articles on testing, check out:

Analyzing Minard's Visualization Of Napoleon's 1812 March

Posted about 1 month back at GIANT ROBOTS SMASHING INTO OTHER GIANT ROBOTS - Home

In The Visual Display of Quantitative Information, Edward Tufte calls Minard’s graphic of Napoleon in Russia one of the “best statistical drawings ever created.” But what makes it so good?

Before we analyze this graphic, we need to know a bit of history.

The year is 1812, and Napoleon is doing pretty well for himself. He has most of Europe under his control, except for the UK. No matter how many times he tried to invade them, he couldn’t break through their defenses. His plan was to place an embargo on them, forcing the other European countries to stop trade with the UK which would weaken them enough so that Napoleon could invade and take over easily.

Czar Alexander of Russia sees that Napoleon was becoming too powerful, so he refuses to participate in this embargo. Angry at Czar Alexander’s decision, Napoleon gathers a massive army of over 400,000 to attack Russia in June of 1812. While Russia’s troops are not as numerous as France’s, Russia has a plan. Russian troops keep retreating as Napoleon’s troops move forward, burning everything they pass, ensuring that the French forces could not take anything from their environment. Eventually the French army follows the Russian army all the way to Moscow during October, suffering major losses from lack of food. By the time Napoleon gets to Moscow, he knows he has to retreat. As winter settles into Europe and the temperature drops, Napoleon’s troops suffer even more losses, returning to France from lack of food, disease, and weather conditions.

Let’s look at all the data we have for this battle.

We have the numbers of Napoleon’s troops by location (longitude), organized by group and direction. We can plot it on line graphs like so.

Next, the temperature experienced by his troops when winter settled in on the return trip.

We also have the path that his troops took to and from Moscow. We can display this information by plotting the paths on a map.

Finally, here is Minard’s graphic.

Source

We have many dimensions of data that takes several individual graphs to represent. Minard’s graphic is quite clever because of its ability to combine all of dimensions: loss of life at a time and location, temperature, geography, historical context, into one single graphic. He shows these various details without distracting text or labels as well. For example, he displays the points where Napoleon’s troops divide into subgroups by breaking out the main bar into branches. He adds thin lines to represent river crossings on the return trip that further decimated Napoleon’s diminishing troops. And he is able to show the drastic loss in life from Napoleon’s decision in just a single corner of the diagram.

Beginning vs end of the campaign

The beginning of Napoleon’s march vs the end of his retreat.

Equally important as what’s shown is what’s not shown — here’s an earlier example of a well-published data visualization:

Source

This graphic was created by William Playfair, largely considered to be the father of information design, in 1786 — about 100 years before Minard’s diagram was made. Playfair is the inventor of the pie chart, the bar graph, and the line graph - statistic graphics we use regularly today. This graphic has gridlines to mark the years and the number of exports. There are five colors, each color representing something different, as well as a number of specific labels in large text. Compare this to Minard’s graphic: when he draws the map, there are no geographical borders and only very minimal geographical plotting. There are many labels describing cities and number of troops, but they are very small. Minard only uses two colors to represent all of the data in the graphic. Additional labels, gridlines, and geographical markings would have made the graphic too overwhelming for the eye, which makes the impact of the data so much stronger.

There are some similarities to designing print data graphics and designing modern interfaces for mobile and web. When we need to translate numbers into graphics to users, we want to focus on communicating lots of information without overwhelming the users with extraneous content, much like Minard with his visualization of Napoleon’s March. Both designers created effective graphics to turn numbers into a narrative, but Minard was able to tell a much more detailed story with his design techniques.

What’s next?

If you would like to learn more about information design, check out Edward Tufte’s The Visual Display of Quantitative Information or any of his other books. You can also take one of his courses in your city.

You can also read:

Episode #470 - June 6th, 2014

Posted about 1 month back at Ruby5

Rails and Sinatra learn to share, Code Climate make a case for Protocol Buffers, read up on HTTP API design, and dat science.

Listen to this episode on Ruby5

Sponsored by New Relic

New Relic is _the_ all-in-one web performance analytics product. It lets you manage and monitor web application performance, from the browser down to the line of code. With Real User Monitoring, New Relic users can see browser response times by geographical location of the user, or by browser type.
This episode is sponsored by New Relic

Share Rails & Sinatra Sessions

Learn a few ways to share authentication between Rails and Sinatra apps.
Share Rails & Sinatra Sessions

Protocol Buffers vs JSON

Read this comparison of JSON and Protocol Buffers and decide for yourself which is right for your service.
Protocol Buffers vs JSON

HTTP API Design Guide

A guide that describes a set of HTTP+JSON API design practices, originally extracted from work on the Heroku Platform API.
HTTP API Design Guide

dat-science

A Ruby library for carefully refactoring critical paths.
dat-science

Episode #469 - June 3rd, 2014

Posted about 1 month back at Ruby5

This week we talk about the brand new RSpec 3 and Git 2, but also how to use bower-rails instead of JavaScript gems, JSON responses with PostgreSQL, and the quirks of Ruby serialization & enumeration.

Listen to this episode on Ruby5

Sponsored by Codeship

Codeship is a hosted Continuous Deployment Service that just works. Set up Continuous Integration in a few steps and automatically deploy when all your tests have passed. Codeship has great support for lots of languages and test frameworks. It integrates with GitHub and BitBucket. You can start with their free plan. Setup only takes 1 minute. You can find them on codeship.io/ruby5 and remember check out their great blog.
Codeship

RSpec 3

Whether you test-drive or not, you should be excited about the release of RSpec 3 yesterday. Myron Marston — the project maintainer — wrote a humongous and deliciously detailed blog post about all these Notable Changes. First, RSpec 3.0 adds better support for Ruby 2.0 features like keyword arguments and Module prepending. That said they dropped Ruby 1.8.6 and 1.9.1 support, but at this point who cares. The RSpec team provided version 2.99 which will output deprecation warnings for anything that changes in RSpec 3.0. It’s pretty great and if you’re worried that your build logs will be littered with deprecations, you can configure RSpec to dump those warnings into a separate file. before(:each) has been aliased to before(:example) and before(:all) to before(:context) in order to make the scope of those hooks more explicit. Every method in the RSpec DSL now yields the RSpec example object instead of exposing an `example` method that could interfere with your own specs. This version also brings an eagerly awaited Zero Monkey Patching mode which should silence one of the biggest criticisms of RSpec: that it monkey patched the Object class with tons of RSpec-specific methods. You can now use expect(object).to equal something, which to me reads quite well and allows for cleaner specs because it makes the expectation part of an example painfully obvious. Zero monkey patching also extends to rspec-mocks, so you now allow(object).to receive(:methodname).and_return(value). Same thing for stubs. You can even expose the RSpec DSL globally in order to avoid monkey patching Ruby’s `main` and Module to call the describe method for example.
RSpec 3

Git 2.0.0

Felipe Contreras, took the time to decipher the Git developers’ cryptic prose to figure out what changed in Git 2.0.0 and why you should care. Instead of pushing all branches that exist locally and on your remote, Git now defaults to “simple” pushing by only dealing with the branch currently checked out. `git add` now defaults to also staging removed files so no need to add the uppercase `A` flag to force it to add all changes. `git add` with no arguments also has more predictable behavior now and will add anything that was modified within the repo.
Git 2.0.0

bower-rails

In the JavaScript world, Bower seems to be the prefered package manager so why not use Bower inside your Rails app instead? This is something the bower-rails gem let’s you do. If you’re not a fan of JSON you can use bower-rails’ own Ruby DSL which even allows you to use the familiar group method from Bundler’s Gemfile. Oh, and just like Bundler, you can declare dependencies stored on Bower’s repository, any public Git repository, or even with a simple GitHub user/repo format. The gem comes with a bunch of rake tasks that allow you to: install, update, and list dependencies as you need to.
bower-rails

Avoid Rails when Generating JSON responses with PostgreSQL

In “Avoid Rails when generating JSON responses with Postgres” Dan McClain shows you all the steps that Rails has to typically go through to get data from Postgres and into your custom JSON format. Then he shows you how to craft a huge Postgres query that will generate pure JSON much quicker than Rails. Dan also created a new PostgresEXT-Serializers gem. This gem monkey patches ActiveModel Serializers and then everytime you try to serialize an ActiveRecord Relation it will take over and push the work down to Postgres. Only caveat is this is a VERY new library, so use with caution.
Avoid Rails when Generating JSON responses with PostgreSQL

Ruby Serialization & Enumeration

It was refreshing to see Xavier Shay from the Square team write about dealing with a weird serialization error with ActiveSupport. In the blog post titled Ruby Serialization & Enumeration, he praises the transparency of Ruby’s libraries, mentions how easy it is to pry them open, jump inside and twiddle stuff around to figure out what’s going wrong. co: Yeah, if you’re never used debugger or pry to jump inside of some of the gems that you use every day, this post shows how useful it can be. That, and it forces you to read more code written by other potentially more skilled developers.
Ruby Serialization & Enumeration

Sponsored by Top Ruby Jobs

If you're looking for a top Ruby job or for top Ruby talent, then you should check out Top Ruby Jobs. Top Ruby Jobs is a website dedicated to the best jobs available in the Ruby community.
Top Ruby Jobs

Sponsored by Ruby5

Ruby5 is released Tuesday and Friday mornings. To stay informed about and active with this podcast, we encourage you to do one of the following:

Thank You for Listening to Ruby5

Episode #468 - May 30th, 2014

Posted about 1 month back at Ruby5

Understanding the magic of routes in Rails, a simple rest-client, using PostGIS with Google Maps, setting up SSL with the latest toys, an examination of Rails vs. Sinatra, and how to get your developers blogging all in this episode of the Ruby5!

Listen to this episode on Ruby5

Sponsored by New Relic

New Relic is _the_ all-in-one web performance analytics product. It lets you manage and monitor web application performance, from the browser down to the line of code. With Real User Monitoring, New Relic users can see browser response times by geographical location of the user, or by browser type.
This episode is sponsored by New Relic

Magical Routes

Routing in Rails...let me count the ways. The URL helpers are very flexible and this blog posts walks you through the different parts, their options, and when to use them.
Magical Routes

REST Client

Probably the simplest REST client for Ruby.
REST Client

PostGIS and Google Maps

This two part blog series walks you through using PostGIS with Rails and Google Maps!
PostGIS and Google Maps

SSL for Rails with Heroku and DNSimple

Setting up SSL doesn't have to be a hassle if you're using the right services. Check out this blog post from thoughtbot to see what a wonderful world it can be!
SSL for Rails with Heroku and DNSimple

Rails vs. Sinatra

Which do you chooose? Rails or Sinatra? Unfortunately for us it is never quite that simple. This blog post from Engine Yard gives a good explanation of the differences in getting started with the two frameworks.
Rails vs. Sinatra

How to Get Developers to Write a Blogpost

Been wanting to write a blog post but letting fear, uncertainty, and doubt get in the way? Check out this post from Netguru to get over yourself.
How to Get Developers to Write a Blogpost

iOS Text Kit Basics

Posted about 1 month back at GIANT ROBOTS SMASHING INTO OTHER GIANT ROBOTS - Home

In the iOS 7 SDK, Apple gave developers programmatic access to Text Kit, an advanced text layout system that lets you easily display and edit rich text in your applications. Although these capabilities are new to iOS, they’ve existed in other contexts (OS X since its first release, and OpenStep before that) for nearly two decades, in what’s called the Cocoa text system. In fact, if you’ve used OS X at all, there is a near 100% chance that you’ve run apps built with the Cocoa text system.

However, for iOS developers, who often are not steeped in the details of OS X development, the details of using the supplied text layout system are new, and may seem mysterious at first. I intend to help you understand the basics of how this works, and see how you can add rich text features to your own apps.

The simplest thing

Let’s start off by making the simplest possible app that shows off some of what Text Kit can do. In Xcode, create a new project using the Single View Application template, and name it Simple Text View. Select Main.storyboard, use the Object Library to find a UITextView object, and drag it out to fill the view of the available view controller; you’ll see blue guidelines appear and the whole thing snap into place when it’s properly centered. Then use the Attributes Inspector to change the text view’s Text attribute from Plain to Attributed. What this does is tell the text view to allow rich text by using an attributed string. An attributed string, which is represented in iOS by the NSAttributedString class, is simply a string that has some attached metadata describing its attributes. This metadata may contain any number of ranges of characters, each with its own set of attributes. For example, you could specify that starting at the fifth character, the next six characters are bold, and that starting at the tenth character, the next five characters are italicized; In that case, the tenth character would be both bold and italicized. In effect,

0123456789ABCDEF

However, plenty of rich text content is created not by programmatically specifying ranges and attributes, but by users working in an editor that lets them create rich text. That’s a use case that is fully supported by UITextView starting in iOS 7.

UITextView in Interface Builder

To prove this, use the Attributes Inspector to modify parts of the “Lorem ipsum” text that the view contains by default. Use the controls in the inspector to change some fonts, adjust paragraph alignment, set foreground and backgroud colors, whatever you want. When you hit cmd-R to run the app in the iOS Simulator or on a device, you’ll see that all the formatting changes you made show up on the device. You can tap to edit the text at any point, and the formatting that applies where the cursor is will carry on to new characters you type, just as you’d expect from any word processor application.

The innards

So far, so good. Even better, it turns out that a few other popular UIKit classes, namely UILabel and UITextField, also allow the use of attributed strings in iOS 7. This means that if you just want to display some rich text in a single rectangular box, you’re all set. Just put a properly configured UILabel where you want to show your rich text, and you’re done! This simple task was remarkably hard to accomplish before iOS 7, so right there we’ve made a huge leap.

But, what if you want to do more? There are certain kinds of layout tricks that none of the UIKit classes can do on their own, out of the box. For example, if you want to make text flow around a graphic, or make a single string fill up one rectangle before spilling into another (as in the case of multiple columns), you’ll have to do more. Fortunately, the innards of Text Kit, which are used by UITextView and the rest, are at your disposal in the form of the NSTextStorage, NSLayoutManager, and NSTextContainer classes. Let’s talk about these one by one:

  • NSTextStorage is actually a subclass of NSMutableAttributedString, which itself is a subclass of NSAttributedString. It adds some functionality that is useful for dealing with a user editing text, and nothing more.
  • NSTextContainer is an abstract description of a two-dimensional box that text could be rendered into. Basically, this class is little more than a glorified size. It contains a few parameters for describing how text should behave when rendered within a box of its size, and that’s about it.
  • NSLayoutManager is the real brains of the operation. It knows how to take an NSTextStorage instance, and layout all the characters it contains into the virtual boxes described by one or more NSTextContainers.

A class like UITextView uses these components to do all its text layout. In fact, UITextView has three properties called textStorage, textContainer, and layoutManager for just this purpose. When UITextView wants to draw its content, it tells its layoutManager to figure out which glyphs (the graphical representations of the characters it contains) from its textStorage can fit within its textContainer, then it tells the layoutManager to actually draw those glyphs at a point inside the text view’s frame. So you see that the design of UITextView itself is inherently limited to a single rectangle. In order to get a feel for how these innards work, I’ll now show you a UIView subclass that will display rich text in multiple columns, a trick that UITextView really can’t pull off in its current form.

Create TBTMultiColumnTextView

In your open Xcode project, create a new subclass of UIView called TBTMultiColumnView. Like UITextView, this class will have textStorage and layoutManager properties. Unlike UITextView, it will keep track of multiple independent text containers and multiple origins for drawing rectangles. The first thing you should do is create a class extension at the top of the file, containing the following properties:

@interface TBTMultiColumnTextView ()

@property (copy, nonatomic) NSTextStorage *textStorage;
@property (strong, nonatomic) NSArray *textOrigins;
@property (strong, nonatomic) NSLayoutManager *layoutManager;

@end

Besides the NSTextStorage and NSLayoutManager instances, we’re also going to maintain an array of origins, each corresponding to an NSTextContainer. We don’t have to hang onto the text containers themselves, because the layout manager keeps its own list, which we can access.

Now, let’s get started with the methods for this class. First, override viewDidLoad as shown here:

- (void)awakeFromNib {
    [super awakeFromNib];
    self.layoutManager = [[NSLayoutManager alloc] init];

    NSURL *fileURL = [[NSBundle mainBundle] URLForResource:@"constitution"
                                             withExtension:@"rtf"];
    self.textStorage = [[NSTextStorage alloc] initWithFileURL:fileURL
                                                      options:
                        @{NSDocumentTypeDocumentAttribute:NSRTFTextDocumentType}
                                           documentAttributes:nil
                                                        error:nil];
    [self createColumns];
}

This method is pretty straightforward. It starts off by creating a layout manager, which we’ll use every time we need to draw this object’s content. Then we read the contents of an RTF file, which we’ve included in our project, into an NSTextStorage instance. Our project contains an RTF file that contains the U.S. constitution, but you can use any RTF document you have at hand. Since this object will need to be redrawn any time the text storage changes, we implement the setter, like this:

- (void)setTextStorage:(NSTextStorage *)textStorage {
    _textStorage = [[NSTextStorage alloc] initWithAttributedString:textStorage];
    [self.textStorage addLayoutManager:self.layoutManager];
    [self setNeedsDisplay];
}

Note that we have a special way of making a new copy of the object that’s passed in. As it turns out, just sending copy to an instance of NSTextStorage actually returns an instance of an immutable parent class (just like you’d expect with, say, an NSMutableString). That’s why we take the step of explicitly creating a new instance based on the received parameter.

At the end of awakeFromNib, we called the createColumns method, which is where most of this class’s work really happens. It looks like this:

- (void)createColumns {
    // Remove any existing text containers, since we will recreate them.
    for (NSUInteger i = [self.layoutManager.textContainers count]; i > 0;) {
        [self.layoutManager removeTextContainerAtIndex:--i];
    }

    // Capture some frequently-used geometry values in local variables.
    CGRect bounds = self.bounds;
    CGFloat x = bounds.origin.x;
    CGFloat y = bounds.origin.y;

    // These are effectively constants. If you want to make this class more
    // extensible, turning these into public properties would be a nice start!
    NSUInteger columnCount = 2;
    CGFloat interColumnMargin = 10;

    // Calculate sizes for building a series of text containers.
    CGFloat totalMargin = interColumnMargin * (columnCount - 1);
    CGFloat columnWidth = (bounds.size.width - totalMargin) / columnCount;
    CGSize columnSize = CGSizeMake(columnWidth, bounds.size.height);

    NSMutableArray *containers = [NSMutableArray arrayWithCapacity:columnCount];
    NSMutableArray *origins = [NSMutableArray arrayWithCapacity:columnCount];

    for (NSUInteger i = 0; i < columnCount; i++) {
        // Create a new container of the appropriate size, and add it to our array.
        NSTextContainer *container = [[NSTextContainer alloc] initWithSize:columnSize];
        [containers addObject:container];

        // Create a new origin point for the container we just added.
        NSValue *originValue = [NSValue valueWithCGPoint:CGPointMake(x, y)];
        [origins addObject:originValue];

        [self.layoutManager addTextContainer:container];
        x += columnWidth + interColumnMargin;
    }
    self.textOrigins = origins;
}

This method is honestly a little longer than we’d like, but for this example it does the job. This method may need to be called multiple times, whenever the view’s coordinates are adjusted (such as when the device rotates), so we need to make sure it can run multiple times without ending up in a weird state. So, it starts off by removing any old text containers that may be attached to the layout manager. It does this because the whole point of this method is to create a fresh set of text containers, and having old ones lying around will only give us grief. This method then calculates appropriate text container sizes depending on the view’s size and some hard-coded values for the number of columns and the amount of margin that should appear between columns. Finally it creates and configures a number of containers and and equal number of points (wrapped in NSValue objects).

Next we’re going to make use of all those containers and points we just created. The drawRect: method tells the layout manager to finally draw its content into each text container. It looks like this:

- (void)drawRect:(CGRect)rect {
    for (NSUInteger i = 0; i < [self.layoutManager.textContainers count]; i++) {
        NSTextContainer *container = self.layoutManager.textContainers[i];
        CGPoint origin = [self.textOrigins[i] CGPointValue];

        NSRange glyphRange = [self.layoutManager glyphRangeForTextContainer:container];

        [self.layoutManager drawGlyphsForGlyphRange:glyphRange atPoint:origin];
    }
}

All we do here is loop over all available text containers and origin points, each time asking the layout manager which glyphs it can fit into the container, then telling the layout manager to draw those glyphs at the origin point.

That’s just about all we need. In order to make things work after device rotation, however, we need to do one more thing. By overriding layoutSubviews, which is called when the view rotates, we can make sure that the columns are regenerated for the new size:

- (void)layoutSubviews {
    [super layoutSubviews];
    [self createColumns];
    [self setNeedsDisplay];
}

That’s all we need to make this class draw rich text in two columns, and automatically adjust for changes in view geometry. To see this in action, go back to the storyboad and follow these steps:

  • Remove the UITextView you added at the start.
  • Find a UIView in the object library, drag it into the view and make it fill the view completely.
  • Use the Identity Inspector to change this object’s class to TBDMultiColumnView.
  • To make sure the view’s geometry changes along with its superview (e.g. when the device rotates), add constraints from the view to its superview for top, bottom, leading, and trailing space. This is most easily accomplished by clicking the Pin button at the bottom of Interface Builder’s editing area, and selecting each of the four red, dashed-line symbols surrounding the little square (which represents the selected view). That sounds complicated, but once you see it, you’ll get it.

Once you’ve taken those final steps, you can build and run in the simulator or on a device, and see your multicolumn display in all its glory!

Multi Column Text View running on iOS
Simulator

Closing remarks

This class demonstrates a technique for creating a view that lets rich text flow across multiple columns in just a few lines of code. But we’re really just scratching the surface here. Besides flowing across multiple rectangles, Text Kit will let you do plenty of other things, including drawing text inside the path of an arbitrary shape, making text flow around other paths, and more. You can learn more about thse techniques by looking at Apple’s iOS Text Kit Overview, as well as their Mac documentation for the Cocoa text system, which is where much of Text Kit’s functionality originated.

How to Share a Session Between Sinatra and Rails

Posted about 1 month back at GIANT ROBOTS SMASHING INTO OTHER GIANT ROBOTS - Home

As Rails developers, we run into Sinatra apps all the time: gems such as Resque which expose a dashboard via Sinatra, legacy Sinatra apps that run alongside a main Rails app, and Sinatra APIs embedded within a Rails app, to name a few examples. Here’s a common problem: how do you share authentication between the apps?

It would be really convenient to be able to do something like this in our Sinatra app:

get '/dashboard' do
  if session[:user_id].present?
    redirect to('/')
  else
    # set up and render dashboard
  end
end

Both Rails and Sinatra are Rack-based, which makes them play surprisingly well together. They can be combined in two ways: via Rack::Builder or via the Rails routes.

Rack::Builder

This method treats Rails as just another Rack app. It creates a middleware stack and mounts the apps at particular urls

# config.ru
map '/api' do
  run MySinatraApp.new
end

map '/' do
  run MyRailsApp::Application.new
end

The standard way to handle authentication in Rails is via a session that is stored in the client’s browser via a cookie. This cookie is base64 encoded in Rails 3.x and encrypted in Rails 4.x. In order to read and write from the session, Rails uses a few middlewares. They (along with the other middlewares that come by default with Rails) can be seen by running rake middleware.

  • ActionDispatch::Cookies
  • ActionDispatch::Session::CookieStore
  • Other middlewares

In order for the Sinatra app to be able to read/write from the Rails session, it needs to have those two middlewares in its stack. The middleware needs to know the name of the cookie that the session is stored in. Finally, the middleware also needs to know the secret token used for signing and encrypting the cookie

# config.ru
map '/api' do
  use Rack::Config do |env| do
    env[ActionDispatch::Cookies::TOKEN_KEY] = MyRailsApp::Application.config.secret_token
  end
  use ActionDispatch::Cookies
  use ActionDispatch::Session::CookieStore, key: '_my_rails_app_session'
  run MySinatraApp.new
end

map '/' do
  run MyRailsApp::Application.new
end

Rails routes

In the previous approach, both the Sinatra and Rails apps were first-class citizens loaded via config.ru. An easier approach is to load all the Sinatra apps via the Rails router. This automatically gives them access to the middlewares loaded (and configured) by Rails.

MyRailsApp::Application.routes.draw do
  mount MySinatraApp.new => '/api'
end

This works because the HTTP request travels through the Rails middleware stack before reaching the router which then sends it to the proper app. When using config.ru, the request is immediately routed to either the Sinatra app or the Rails app so we need to manually add the middleware in front of the Sinatra app.

Which approach to take?

Mounting a Sinatra app via the Rails routes is the standard way to embed a Sinatra app within a Rails app. Since they both share the same middleware stack, you get shared sessions for free. However, if you need a custom middleware stack for your Sinatra app then the Rack::Builder approach is the way to go.

Further reading

Learn more about Rails and Rack

Phusion Passenger 4.0.44 released

Posted about 1 month back at Phusion Corporate Blog


Phusion Passenger is a fast and robust web server and application server for Ruby, Python, Node.js and Meteor. Passenger takes a lot of complexity out of deploying web apps, and adds powerful enterprise-grade features that are useful in production. High-profile companies such as Apple, New York Times, AirBnB, Juniper, American Express, etc are already using it, as well as over 350.000 websites.

Phusion Passenger is under constant maintenance and development. Version 4.0.44 is a bugfix release.

Phusion Passenger also has an Enterprise version which comes with a wide array of additional features. By buying Phusion Passenger Enterprise you will directly sponsor the development of the open source version.

Recent changes

Version 4.0.43 has been skipped because a compilation problem on OS X Mountain Lion was found soon after the gem was pushed. The changes in 4.0.34 and 4.0.44 combined are as follows.

  • The issue tracker has now been moved from Google Code to Github. Before version 4.0.44 (May 29 2014, commit 3dd0964c9f4), all issue numbers referred to Google Code. From now on, all issue numbers will refer to Github Issues.
  • On Ruby, fixed nil being frozen on accident in some cases. See issue #1192.
  • Introduced a new command passenger-config list-instances, which prints all running Phusion Passenger instances.
  • Introduced a new command `passenger-config system-metrics, which displays metrics about the system such as the total CPU and memory usage.
  • Fixed some compilation problems caused by the compiler capability autodetector.
  • System metrics such as total CPU usage and memory usage, are now sent to Union Station in preparation for future features.

Installing or upgrading to 4.0.44

OS X OS X Debian Debian Ubuntu Ubuntu
Heroku Heroku Ruby gem Ruby gem Tarball Tarball

Final

Fork us on Github!Phusion Passenger’s core is open source. Please fork or watch us on Github. :)

<iframe src="http://ghbtns.com/github-btn.html?user=phusion&amp;repo=passenger&amp;type=watch&amp;size=large&amp;count=true" allowtransparency="true" frameborder="0" scrolling="0" width="170" height="30"></iframe><iframe src="http://ghbtns.com/github-btn.html?user=phusion&amp;repo=passenger&amp;type=fork&amp;size=large&amp;count=true" allowtransparency="true" frameborder="0" scrolling="0" width="170" height="30"></iframe><iframe src="http://ghbtns.com/github-btn.html?user=phusion&amp;type=follow&amp;size=large&amp;count=true" allowtransparency="true" frameborder="0" scrolling="0" width="190" height="30"></iframe>

If you would like to stay up to date with Phusion news, please fill in your name and email address below and sign up for our newsletter. We won’t spam you, we promise.



Workflows for Writing Migrations With Rollbacks in Mind

Posted about 1 month back at GIANT ROBOTS SMASHING INTO OTHER GIANT ROBOTS - Home

thoughtbot’s dotfiles include an alias mapping migrate to

rake db:migrate db:rollback && rake db:migrate

It is also a good practice in our workflow to use the migrate alias in place of rake db:migrate. Let’s explore what this command does and why we recommend it.

Reversibility

rake db:migrate db:rollback will run any pending migrations and then attempt to roll back those migrations. If the migration and rollback are successful (signified by &&), rake db:migrate will then run the migration again. If the command is not successful, an error will be thrown. In this way we can be confident our migrations' down commands are syntactically valid (no typos) and logically valid (no invalid castings of values, for example).

Beyond having a short alias in place of a multi-word rake command, ensuring that each migration we write is reversible is very handy for iterative development locally and for dreaded production rollbacks.

An Exception

One time when we break this guideline is when we explicitly require an irreversible migration because the transformation is destructive. In the special circumstances when this behavior is required, the down command should raise an ActiveRecord::IrreversibleMigration exception as stated by the docs. As a result, a rollback is impossible and we’ll run rake db:migrate instead of migrate.

What’s next

We have found having a frictionless way of running migrations in both directions has saved us lots of time and headaches.

If you’d like to learn more about handling irreversible migrations check out the following resources:

Happy migrating!

Writing a Domain-Specific Language in Ruby

Posted about 1 month back at GIANT ROBOTS SMASHING INTO OTHER GIANT ROBOTS - Home

A Domain-Specific Language, or DSL, is “a programming language of limited expressiveness focused on a particular domain”. It makes tasks in its domain easier by removing extraneous code for a particular task and allowing you to focus on the specific task at hand. It also helps other people read the code, because the purpose of the code is so clear.

Here’s a little Internal DSL in Ruby:

Smokestack.define do
  factory User do
    name "Gabe BW"
    pet_name "Toto"
  end
end

user = Smokestack.build(User)
puts user.name == 'Gabe BW'  # true
puts user.pet_name == 'Toto' # true

other_user = Smokestack.build(User, name: "Bob")
puts other_user.name == 'Bob'      # true
puts other_user.pet_name == 'Toto' # true

Let’s go over each part and how it works.

Set up

First, let’s define User and Post classes that we’ll be using in our factory:

class User
  attr_accessor :name, :pet_name
end

class Post
end

We’ll be referring to these throughout the post.

Identifying method calls

When I first looked at code like Smokestack.define above, I had a hard time identifying where methods were being called. Let’s add parentheses:

Smokestack.define do
  factory(User) do
    name("Gabe B-W")
    pet_name("Toto")
  end
end

That’s better. Now we can see that Smokestack.define takes a block, and the factory method takes a class, like User, and a block. But where is the factory method coming from?

instance_eval

To find out, we need to look at the instance_eval instance method, available on every class. According to the docs:

Evaluates a string containing Ruby source code, or the given block, within the
context of the receiver (obj). In order to set the context, the variable self is
set to obj while the code is executing, giving the code access to obj’s instance
variables.

Here’s an example:

class DefinitionProxy
  def factory(factory_class)
    puts "OK, defining a #{factory_class} factory."
  end
end

definition_proxy = DefinitionProxy.new
definition_proxy.instance_eval do
  factory User
  factory Post
end

That code prints out this:

OK, defining a User factory.
OK, defining a Post factory.

The factory User and factory Post are evaluated in the context of the definition_proxy instance. That means that factory User in the definition_proxy.instance_eval block is actually calling definition_proxy.factory(User).

Now let’s add it to Smokestack:

module Smokestack
  def self.define(&block)
    definition_proxy = DefinitionProxy.new
    definition_proxy.instance_eval(&block)
  end
end

Smokestack.define is now the entry point for our DSL. It takes a block, then evaluates that block in the context of a DefinitionProxy instance.

Registering Factories

Now that our code sort of works, let’s register factories. Factories aren’t helpful unless we can refer to them, and to do that we need a central registry. The simplest registry is a hash that maps factory classes to factories.

The following code gives us Smokestack.registry:

module Smokestack
  @registry = {}

  def self.registry
    @registry
  end
end

Let’s change the factory method to register factories when they’re declared:

class DefinitionProxy
  def factory(factory_class)
    factory = lambda { puts "OK, creating a #{factory_class}." }
    Smokestack.registry[factory_class] = factory
  end
end

Instead of printing out a message immediately, we wrap it in a lambda. This means that we can store that lambda in the registry, and call factories whenever we like after registering them:

Smokestack.define do
  factory User
end

Smokestack.registry[User].call # => "OK, creating a User."
Smokestack.registry[User].call # => "OK, creating a User."

Diving Deeper

Now we can declare that a factory exists, but it’s not really a factory yet. It doesn’t actually initialize objects. Let’s look at the original code again:

factory User do
  name "Gabe BW"
  pet_name "Toto"
end

We want that code to declare a factory that does the following:

user = User.new
user.name = "Gabe BW"
user.pet_name = "Toto"
return user

Like Factory Girl, we’ll assume that:

  • factory User refers to the User class
  • The User class has setter methods for every attribute in the factory (e.g. name=)

Each factory might have different setter methods (e.g. pet_name=), so we’ll use method_missing to handle every case.

Let’s take a stab at it:

class Factory < BasicObject
  def initialize
    @attributes = {}
  end

  attr_reader :attributes

  def method_missing(name, *args, &block)
    attributes[name] = args[0]
  end
end

class DefinitionProxy
  def factory(factory_class, &block)
    factory = Factory.new
    if block_given?
      factory.instance_eval(&block)
    end
    Smokestack.registry[factory_class] = factory
  end
end

DefinitionProxy#factory now passes its block to a Factory instance, then stores the Factory instance in the registry. If there’s no block (i.e. if block_given? evaluates to false), then the factory does not evaluate the block, but is still put in the registry. Here’s a case where we have no block, because Post has no attributes:

Smokestack.define do
  factory Post
end

Factory inherits from BasicObject, which is a class with very few methods defined. It’s great for use in metaprogramming like this, where you want every instance method call to trigger method_missing.

We now have all of the Smokestack.define DSL working, with factories and a registry to map factory names to stored factories. Let’s add Smokestack.build.

Smokestack.build

Smokestack.build(User) needs to do the following:

  • Grab the user factory
  • Set attributes on the user, with optional overrides
  • Return the user

To get the attributes, we can grab factory.attributes from the user factory in the registry. Let’s have Smokestack.build take an optional second parameter, overrides, which allows people to pass custom values.

Here’s the code:

module Smokestack
  def self.build(factory_class, overrides = {})
    instance = factory_class.new

    # Set attributes on the user
    factory = registry[factory_class]
    attributes = factory.attributes.merge(overrides)
    attributes.each do |attribute_name, value|
      instance.send("#{attribute_name}=", value)
    end

    # Return the user
    instance
  end
end

Putting it all together

Here’s what we ended up with:

module Smokestack
  @registry = {}

  def self.registry
    @registry
  end

  def self.define(&block)
    definition_proxy = DefinitionProxy.new
    definition_proxy.instance_eval(&block)
  end

  def self.build(factory_class, overrides = {})
    instance = factory_class.new
    factory = registry[factory_class]
    attributes = factory.attributes.merge(overrides)
    attributes.each do |attribute_name, value|
      instance.send("#{attribute_name}=", value)
    end
    instance
  end
end

class DefinitionProxy
  def factory(factory_class, &block)
    factory = Factory.new
    factory.instance_eval(&block)
    Smokestack.registry[factory_class] = factory
  end
end

class Factory < BasicObject
  def initialize
    @attributes = {}
  end

  attr_reader :attributes

  def method_missing(name, *args, &block)
    @attributes[name] = args[0]
  end
end

Let’s run it through its paces:

Smokestack.define do
  factory User do
    name "Gabe BW"
    pet_name "Toto"
  end
end

user = Smokestack.build(User)
puts user.name
#=> "Gabe BW"
puts user.pet_name
#=> "Toto"

other_user = Smokestack.build(User, name: 'Bob')
puts other_user.name
#=> "Bob"
puts other_user.pet_name
#=> "Toto"

Neat.

How could this be made better?

The use of a class directly (factory User) looks out-of-place if you’re familiar with Rails idioms or Factory Girl. To make this more Rails-y, we’d use a symbol like factory :user. To make this work, we can use plain Ruby or ActiveSupport:

# Plain Ruby
Object.const_get(:user.capitalize) #=> User

# ActiveSupport
:user.capitalize.constantize #=> User

Further Reading

For more examples of DSLs, check out factory_girl or the Rails routes.

Finding the perfect house using open data

Posted 2 months back at Encytemedia - Home

1283d6a2014211e3a98422000aa80fc9_7

My childhood backyard.

Growing up in rural Mississippi had its perks. Most days my brother and I would come home from school, grab a snack from the fridge, and head outside to fish in the pond tucked behind the tree line or play basketball with the neighborhood kids. It was very much a community where everyone knew everyone. I had known many of the kids from my graduating class since second grade and my parents knew their parents since highschool and earlier.

As beautiful as my hometown was, it was, like many small towns, economically depressed and void of all but the necessities. As I grew older, I became frustrated by this. We had one small grocery store, one stop light, two movie rental places and not a single fast food restaurant. We had no book stores, no electronic stores, no big-box stores and only a couple of places to grab a bite to eat.

Truth be told, the gas station (one of those big ones, forever known as “The BP” long after a name change) was where we picked up most of our take out. When highway 72 was expanded to four lanes, a nearby gas station was converted to a “super” station. It was packed with a pizza place, fresh sub sandwiches, and the best chicken strips that have ever graced the space below a heat lamp. It was the community watering hole.

The lack of access eventually wore on me. As I started to grow my design skills (my Hail Mary escape from factory work), I would hear of my peers in larger cities going out to eat, to the movies, or just having a beer at a nearby bar. Beer, by the way, was illegal where I grew up. Not just the consumption of it, the mere possession of it.

6307658831_df66e3f10d_b

Portland - Oregon by Patrick M. License CC BY-NC-SA 2.0

By 2007, after a couple of years on the outskirts of Memphis, TN, I had finally had enough and convinced my wife to move to Portland, OR. We knew very little about Portland at the time. In fact, we knew so little about the Pacific Northwest, we moved in the dead of winter, in a sports car, driving through the Cascade mountain range. It’s not exactly something I’m proud of; a hilariously ill-conceived cross-country trip.

When we moved to Portland we decided we wanted to be in the center of it all. There was so much life around us; so much happening relative to our rural upbringing. I wanted to be as close to Downtown as I could be so I could go as often as I liked.

We eventually settled on the Pearl District. A relatively new residential development that was previously occupied by a rail yard. Finally, I would have the access that I once craved. Almost anything I wanted was a short walk or streetcar ride away. All that I wished for growing up, I would have.

8bb23018889a11e18cf91231380fd29b_7

Fast forward 7 years and we’re still in the Pearl District. We’ve added a member to our family who now desires access to the things I had while growing up. He wants a yard to play in, a basketball goal and a proper house where he can get excited without disturbing our neighbors.

It’s an interesting scenario. The Pearl District and Downtown aren’t exactly teaming with affordable single family homes and the further you move out of the city center, generally the less access you have to the many things a dense urban area has to offer. But, in reality, I only wished for a couple of things out of a new location.

The journey begins

After thinking about the problem, I decided to list out a set of criteria for a location I would want to live. Other factors will eventually come into play, but I wanted to narrow down the city into “target zones”—that is, zones that meet a set of defined criteria.

  • Walking distance to a grocery store: Living across the street from a grocery store has spoiled me.
  • Walking distance to a rail stop: This will allow me to get to other locations in the city without a car relatively quickly. One could argue the bus system is just as good, but I would argue that it isn’t and I much prefer rail.

I defined walking distance as ~5 blocks, but ~10 blocks is still a pretty sane distance. I want to be close to a grocery store and close to a MAX or Streetcar stop. Unfortunately, none of the real estate applications I tried had a feature like this so I decided to create what I needed using open data that I had already been working with for some time now.

Gathering the data

This section makes heavy use of GDAL and PostGIS. Both of which can be installed using homebrew on OSX.

We’ll need 3 open datasets.

After downloading the data, we’ll want to reproject the building dataset to EPSG:4326 so that all of the data shared the same projection. EPSG:4326 (WGS84) is a common projection and the projection of the other two datasets so I went with that.

ogr2ogr -t_srs EPSG:4326 -f "ESRI Shapefile" building-footprints.shp  Building_Footprints_pdx.shp

Note: EPSG:2913, the original projection of the building dataset, is probably the more accurate choice if we were concerned with a high level of precision.

Now we need to create a PostGIS-enabeld Postgres database

createdb portland
psql -c "create extension postgis" -d portland

Finally, we need to import the datasets to our freshly created Postgres database. See the shp2pqsql docs for an explanation of the flags used. Essentially we want to import as latin1 (there are some encoding errors in the building dataset), force 2d geometry and create an index on the geometry column.

shp2pgsql -W "latin1" -t 2D -I -D -d -s 4326 building-footprints.shp building_footprints | psql -d portland
shp2pgsql -W "latin1" -t 2D -I -D -d -s 4326 osm-polygons.shp osm_polygons | psql -d portland
shp2pgsql -W "latin1" -t 2D -I -D -d -s 4326 trimet-rail-stops.shp trimet_rail_stops | psql -d portland

After we have the data imported into Posgtres, we can begin to find target geometries (buildings) that meet the criteria we set. The first thing we want to do is find the zones around all supermarkets using st_expand. Our units are decimal degrees and 0.0045 is about the desired distance of ~5 blocks. We’re not too worried about being a little off here.

select st_expand(geom, 0.0045) as zone, 5 as score from osm_polygons where osm_polygons.shop='supermarket'

zones

At this point, we have large rectangle geometries. As you can tell from the image above, some buildings lie in overlapping zones. We want to score those buildings for every zone they intersect with. In similar fashion, we want to find the zones around rail stops and public parks.

The next thing we want to target individual buildings instead of merely drawing a large box around a zone. We can find all buildings that intersect a zone using st_intersects.

select * from supermarket_zones inner join buildings on st_intersects(supermarket_zones.zone, buildings.geom) where buildings.subarea='City of Portland'

screen shot 2014-05-24 at 11 42 14 am

Finally, we want to group identical geometries, sum the score and stuff the target buildings into a new table. We don’t necessarily need to add the target buildings to a new table, but continuously running these queries across the entire building set can be slow.

select sum(score) as rank, gid, geom into target_homes from target_buildings group by 2, 3;

Here’s what everything looks like combined which can be run using psql -f score-buildings.sql -d portland.

<script src="https://gist.github.com/Caged/d9b988485b813b14c69b.js"> </script>

Styling the results

Mapbox has a great crash course on TileMill. I highly recommend you check it out if you’re unfamiliar with it.

The last major thing we need to do is to visualize the results on a map. For this, I’ll use the open source editor Tilemill by Mapbox. This step is pretty straight forward since we’ve already done the hard work of extracting and scoring the buildings we’re interested in. We only need to supply Tilemill with the name of the table we stored our target homes in.

screen shot 2014-05-24 at 11 54 05 am

Finally, let’s fill each building with a color based on its score using CartoCSS.

#homes {
  [rank >= 5] {
    polygon-fill: #ea97ca;
  }

  [rank >= 10] {
    polygon-fill: #3581ac;
  }

  [rank >= 15] {
    polygon-fill: #4dac26;
  }

   [rank >= 20] {
    polygon-fill: #a9bb29;
  }
}

We can add more layers to help give some context to our results. Here’s what I ended up with after adding layers for rail lines, rail stops and supermarkets.

screen shot 2014-05-24 at 12 04 49 pm

And that’s it. Now I have a good idea of locations I can check out in my quest to find a house nearby a supermarket and rail line. Nothing like quickly grabbing a beer for a backyard barbecue and a little game of basketball. And hey, when the Trail Blazers play? I’ll just walk a few blocks and hop on the MAX.

Episode #467 - May 23rd, 2014

Posted 2 months back at Ruby5

Some new stuff(Rspec3 rc1, ActiveJob), some cool stuff(Devise-two-factor, Camcorder), and some educational stuff (Teaching kids of Pis, Weirich on Exceptions) in this RubyLoco-powered edition of Ruby5!

Listen to this episode on Ruby5

This episode is sponsored by New Relic

Brought to you by NewRelic
This episode is sponsored by New Relic

ActiveJob

Active Job is a framework for declaring jobs and making them run on a variety of queueing backends. In just a few days, it has gone from a neat idea to a functional job abstraction on top of 8 Ruby Job queue libraries.
ActiveJob

devise-two-factor

Devise-two-factor is a minimalist extension to Devise which offers support for two-factor authentication
devise-two-factor

inch pages

If you are a gem developer or maintain a library you probably already use badges in your README to show that your tests are passing and your code isn't a horrible mess in need of refactoring. Now you can also show that you documented your project properly.
inch pages

camcorder

Need to have VCR-like functionality for more than just http? Wait no more. This gem allows you to record arbitrary method invocations from arbitrary objects.
camcorder

Kids and Pis

Last fall I volunteered at my kids school and taught over 200 kids the ‘hour of code curriculum’. I’m trying to get together a summer program for about 15 kids around 5th grade, giving them raspberry pis, support, and ideas on fun stuff to do. I’m using Ruby5 as a soapbox to find others doing similar things. If you’re interested in collaborating as teachers and doing something in your area, reach out on twitter (@bokmann)
 Kids and Pis

Active Record Soup

Once upon a time there was a small but prosperous village...
Active Record Soup

Weirich on Exceptions

Writes Avdi Grim, "Back in 2011 I was doing research for the talk that became Exceptional Ruby, and Jim Weirich was nice enough to let me pick his brain on the topic. I was reminded of this email today, and thought I’d share it."
Weirich on Exceptions

Working Effectively with Unit Tests

Posted 2 months back at Jay Fields Thoughts

Unit Testing has moved from fringe to mainstream, which is a great thing. Unfortunately, as a side effect developers are creating mountains of unmaintainable tests. I've been fighting the maintenance battle pretty aggressively for years, and I've decided to write a book that captures what I believe is the most effective way to test.

From the Preface

Over a dozen years ago I read Refactoring for the first time; it immediately became my bible. While Refactoring isn’t about testing, it explicitly states: If you want to refactor, the essential precondition is having solid tests. At that time, if Refactoring deemed it necessary, I unquestionably complied. That was the beginning of my quest to create productive unit tests.

Throughout the 12+ years that followed reading Refactoring I made many mistakes, learned countless lessons, and developed a set of guidelines that I believe make unit testing a productive use of programmer time. This book provides a single place to examine those mistakes, pass on the lessons learned, and provide direction for those that want to test in a way that I’ve found to be the most productive.
The book does touch on some theory and definition, but the main purpose is to show you how to take tests that are causing you pain and turn them into tests that you're happy to work with.

For example, the book demonstrates how to go from...

looping test with many (built elsewhere) collaborators
.. to individual tests that expect literals, limit scope, explicitly define collaborators, and focus on readability
.. to fine-grained tests that focus on testing a single responsibility, are resistant to cascading failures, and provide no friction for those practicing ruthless Refactoring.
As of right now, you can read the first 2 chapters for free at https://leanpub.com/wewut/read

I'm currently ~25% done with the book, and it's available now for $14.99. My plan is to raise the price to $19.99 when I'm 50% done, and $24.99 when I'm 75% done. Leanpub offers my book with 100% Happiness Guarantee: Within 45 days of purchase you can get a 100% refund on any Leanpub purchase, in two clicks. Therefore, if you find the above or the free sample interesting, you might want to buy it now and save a few bucks.

Buy Now here: https://leanpub.com/wewut

SSL for Rails with Heroku and DNSimple

Posted 2 months back at GIANT ROBOTS SMASHING INTO OTHER GIANT ROBOTS - Home

SSL certificates can be intimidating but Heroku and DNSimple make the process easy. The following steps should take us less than 15 minutes.

Buy the SSL certification from DNSimple

Buy a wildcard certificate from DNSimple. The wildcard (*) lets us use the same certificate on staging, production, and any other future subdomains (api, etc.).

Prepare the SSL certificate

Follow the wildcard certificate instructions to get .pem, .crt, and .key files prepared.

Follow these instructions to complete .key preparation, provision the SSL addon from Heroku, and add the certificate to Heroku:

heroku certs:add server.crt server.key

Replace it with:

heroku certs:add *.{pem,crt,key}

Otherwise, we might see an error like:

Updating SSL Endpoint myapp.herokussl.com for [heroku-app]... failed
 !    Internal server error.

Get SSL endpoint from Heroku

Run:

heroku certs

This provides us the correct end point for the SSL enabled domain. This is a domain that looks like tokyo-2121.herokussl.com.

Add Heroku SSL endpoint to DNSimple

Next, go to our DNSimple dashboard and update/add the CNAME record for the SSL enabled domain to point to (e.g.) tokyo-2121.herokussl.com.

Prepare Rails app

Make a one-line configuration change in our staging and production environment config files within our Rails app:

# config/environments/{staging,production}.rb
config.force_ssl = true

Deploy that change.

Now, if users type “ourdomain.com”, they should be redirected to “https://www.ourdomain.com” and our browser’s URL bar should display its appropriate indicator (perhaps a green lock) declaring the SSL certificate is valid.

What’s next?

Read our production checklist to see a full list of things, including SSL, that should be done before an application goes live.
